Products Description
Technical Specifications
Model: PFTL201C, Rated load:10kN
Part Number:3BSE007913R0010
Measuring Direction: Horizontal force measurement
Extended Load:15kN; Max overload in measuring direction:100kN
Transverse Permitted Load:100kN
Accuracy: ±0.5% full scale
Sensor Technology: ABB Pressductor magnetic force sensing principle
Material: Stainless steel housing
Protection Class: IP67
Operating Temperature:‑5℃ ~ +50℃
Connection: Industrial circular connector
Mounting: Pillow‑block type installation for roll bearing seats
Weight: approx 2.1kg
PFTL201C 10KN (3BSE007913R0010) is ABB Pressductor Pillow‑Block horizontal tension load cell. It adopts proprietary magnetic Pressductor technology to measure horizontal force on roll bearing seats, exclude interference from roll self‑weight, realize accurate strip tension monitoring.
Stainless‑steel robust structure delivers excellent vibration resistance and high overload tolerance. IP67 protection adapts to harsh dusty and wet workshop environments. It outputs force‑proportional signal to connect with ABB PFTL series signal processing units, completes closed‑loop tension control for production lines. Simple pillow‑block mounting design reduces installation and calibration workload.
Mainly used for metal rolling, paper‑making, coating and winding processes. When replacing spare parts, confirm complete model, rated load and part number. Ensure correct installation orientation according to force direction mark on sensor surface. Suitable for on‑site replacement and long‑term spare stocking of existing strip tension measurement systems.
