ABB UAC389AE02 HIEE300888R0002 Network Communication Processor Module

Technical Specifications

Model: UAC389AE02

Part Number: HIEE300888R0002

Brand: ABB

Product Type: INFI‑NET ring network communication processor module

Matching System: ABB Symphony Harmony, INFI90 DCS distributed control system

Processor: Motorola 68000 series industrial microprocessor

Network Interface: INFI‑NET redundant ring network interface, communication rate 10Mbps

Network Topology: Support redundant ring and bus topology

Power Supply: System backplane 24VDC power supply

Function: Process data forwarding, control logic execution, I/O module resource management

Feature: Support hot‑swap, redundant ring network fault self‑healing

Operating Temperature: 0℃ ~ +60℃, non‑condensing

Protection Class: IP20

Weight: 0.75kg

Mounting: Rack slot plug‑in installation

Compatible System: ABB Symphony, INFI90 DCS system

Core Function: Realize high‑speed transmission of massive real‑time process data on INFI‑NET ring network, execute control logic, coordinate and manage each I/O module of the system, guarantee stable operation of DCS control network.

Product Details

The UAC389AE02 HIEE300888R0002 is core Network Communication Processor for ABB Symphony INFI90 DCS platform, it acts as important INFI‑NET Ring Interface Board.

This module undertakes core tasks such as real‑time process data transmission on INFI‑NET ring network, control logic operation and I/O module management. It adopts redundant ring network design, when single‑point network fault occurs, it can realize automatic link switching to avoid network paralysis. Hot‑swap function supports online replacement without shutting down the whole system, reduce equipment maintenance downtime.

Front‑panel LED indicators display power status, ring network running status, data transceiver and fault alarm information. Built‑in complete self‑diagnosis function can detect ring network abnormality, communication interruption and internal hardware failure, fault information can be uploaded to upper monitoring station. Industrial‑grade circuit design adapts to harsh working conditions of power plant control cabinet.

Standard rack plug‑in structure, convenient for installation and maintenance. Widely applied in thermal power, petrochemical, pulp‑paper industries. It is key spare hardware for INFI90 system transformation, ring network fault maintenance and defective UAC389AE02 module replacement.
