Control Techniques UNI1404 Unidrive Servo Drive Unit

Module Feature

UNI1404 is Unidrive classic series universal AC drive manufactured by Control Techniques. This unit is fully tested and functional verified. It supports V/F control, open-loop vector, closed-loop vector and high-performance servo control, compatible with Unimotor series brushless servo motors and induction motors. Equipped with built-in digital and analog I/O terminals, optional expansion slots for encoder or fieldbus communication cards. Widely used in machine tools, packaging machinery, conveying systems and industrial automation motion equipment.

Working principle

Three-phase AC input is rectified to DC bus voltage. The IGBT power module converts DC into adjustable frequency and adjustable voltage AC output. The drive receives motion command from upper controller, compares command signal with encoder feedback signal, dynamically calculates output torque to realize closed-loop speed, torque or position control. Built-in brake transistor absorbs regenerative energy during motor deceleration.

Onboard components

Input rectifier bridge,IGBT power stage,main control PCB,status LED indicators,control terminal block,dynamic braking transistor,heat sink,expansion card slot.

LED indicators

Power indicator,run status LED,fault alarm LED.

Hardware self-diagnosis

Overvoltage,undervoltage,overcurrent,overtemperature,output short circuit,earth fault,encoder signal loss,motor overload monitoring.

Programming software

CTSoft software,supports motor parameter auto-tune,real-time motion monitoring,fault log reading and parameter backup & restore.

Electrical & Process Parameters

Model:UNI1404 Brand: Control Techniques Device type: Unidrive Classic Universal AC Drive Input voltage:380 ~ 480VAC 3 phase Control mode: V/F, open-loop vector, closed-loop vector, servo control Feedback:Incremental encoder input,optional resolver / absolute encoder via option card Cooling:Forced air cooling Protection:Over current,over voltage,under voltage,over temperature,short circuit,earth fault protection

Mechanical & Structure

Mounting:Panel mounting Protection class:IP00 Housing:Metal frame housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:20~80% non-condensing Certification: CE compliant Status: Pre-tested Control Techniques UNI1404 Unidrive drive for industrial motion control

Installation

Follow ESD safety procedure before handling. Mount vertically with enough ventilation space around heat sink. Connect three-phase main power, motor cable and encoder feedback cable. Use shielded control cables to reduce EMI interference. Power on and complete motor auto-tune before commissioning.

Interface

Main power terminal,motor output terminal,control I/O terminal,encoder connector,expansion card slot,keypad port.

Diagnostic

Encoder loss fault: loose wiring or encoder hardware damage. Over current: motor short circuit, damaged cable or mechanical jamming. Overheat: clogged heat sink or continuous overload. Under voltage: unstable input power or phase loss.

Product Brief

Tested Control Techniques UNI1404 Unidrive universal AC drive, multi-mode motion control, supports Unimotor servo motors, widely used for closed-loop speed, torque and position control in industrial automation systems.
