DANAHER MOTION 401-34328-01 Servo Motor

Technical Specifications

Model：401-34328-01 Brand：DANAHER MOTION Product Type: Permanent magnet rotary servo motor for industrial motion control

Motor Feature: Motor type: Brushless permanent magnet synchronous motor Feedback device: Built-in incremental encoder Output characteristic: High torque density, low cogging torque Rotation direction: CW / CCW reversible

Electrical Parameters: Rated voltage: 230VAC Rated speed: 3000 rpm Rated torque: 4.2 Nm Rated current: 5.6A

Mechanical & Structure: Shaft: Keyway output shaft Housing: Aluminum alloy housing Mounting: Flange mounting Protection class: IP65

Environmental: Operating temperature: -20℃ ~ +40℃ Ambient humidity:0~85% non-condensing Certification: UL, CE approved Weight: Approx 4.7kg

System compatibility

401-34328-01 belongs to DANAHER MOTION servo motor family. Compatible with matching DANAHER MOTION servo drives and mainstream PLC motion controllers. Widely applied in machine tools, packaging equipment and textile machinery for single and multi-axis motion control.

Function

401-34328-01 is brushless permanent magnet servo motor manufactured by DANAHER MOTION. It converts electric energy into precise mechanical rotation under the control of servo drive. Built-in encoder feeds back real-time position and speed signal to realize closed-loop control. It provides stable torque output for automated production axis.

Installation

Follow lockout/tagout safety procedure before installation. Mount the motor flange on machine base. Connect power cable and encoder cable strictly follow DANAHER MOTION official wiring manual. Perform mechanical alignment, home calibration and running test during commissioning.

Interface

Power connector,encoder connector,keyway shaft,flange mounting holes,aluminum alloy housing for DANAHER MOTION 401-34328-01.

Feature

Original DANAHER MOTION 401-34328-01 brushless servo motor,low cogging,high positioning accuracy,IP65 protection,stable continuous operation,UL & CE certified. This spare unit is used for automation equipment axis drive,motion system retrofit and hardware replacement.

Diagnostic

Motor no rotation: Inspect servo drive enable signal,power and encoder wiring. Abnormal noise: Check coupling alignment, bearing damage and mechanical stuck. Overheat alarm: Verify load condition,ambient temperature and ventilation. Position drift: Inspect encoder connection,shield grounding and mechanical backlash.

Product Brief

401-34328-01 is DANAHER MOTION permanent magnet brushless servo motor with high torque density,matched with Danaher servo drives,classic spare part for CNC and automation machinery motion axis.
