DANAHER MOTION M.1302.1162 Servo Drive

Technical Specifications

Model：M.1302.1162 Brand：DANAHER MOTION Product Type: M series high-performance digital servo amplifier for industrial motion control

Drive Feature: Control mode: Position / Speed / Torque control Command input: Pulse & direction, ±10V analog command Built-in function: Electronic cam, master-slave gearing, homing routine, S-curve acceleration PWM switching frequency:10kHz

Electrical Parameters: Input voltage:230VAC single phase Continuous output current:13A Peak output current:26A Control power supply:24VDC

Mechanical & Structure: Housing: Reinforced metal sheet enclosure Mounting: DIN rail mounting Cooling: Forced air cooling Protection class:IP20

Environmental: Operating temperature:0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved Weight: Approx 2.3kg

System compatibility

M.1302.1162 belongs to DANAHER MOTION M series servo drive family. Compatible with DANAHER MOTION brushless synchronous servo motors and mainstream motion controllers. Widely used for medium-heavy load packaging machinery,material handling systems and CNC single-axis high-precision motion control.

Function

M.1302.1162 is high-performance digital servo amplifier manufactured by DANAHER MOTION. It receives motion command signals from upper controller and outputs adjustable high drive power to servo motor. Closed-loop control is realized through encoder feedback to achieve high-precision positioning and fast dynamic response. Built-in electronic cam and master-slave gearing functions support synchronous motion applications.

Installation

Follow lockout/tagout safety procedure before installation. Mount M.1302.1162 on DIN rail inside electrical cabinet. Connect power cable, motor cable and encoder cable strictly follow DANAHER MOTION M series wiring manual. Complete motor auto-tuning and full-load motion test during commissioning.

Interface

AC power terminals, motor output terminals, encoder port, digital I/O terminals, RS232 communication port, status LED indicator for DANAHER MOTION M.1302.1162.

Feature

Original DANAHER MOTION M.1302.1162 digital servo drive,large continuous and peak current,forced air cooling,DIN rail installation,multiple control modes,UL & CE certified. This spare unit is used for medium-heavy load automation axis control,motion system upgrade and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage,undervoltage,overcurrent and overtemperature faults. Motor no rotation: Check power wiring,encoder connection and drive enable signal. Positioning deviation: Re-tune servo gain,inspect encoder signal and mechanical backlash. Abnormal vibration: Adjust servo parameters,check motor and coupling alignment.

Product Brief

M.1302.1162 is DANAHER MOTION M series high performance digital servo amplifier,supports multi-mode control,matched with medium high-torque Danaher brushless servo motors,classic spare part for CNC and medium-heavy industrial automation motion system.
