DANAHER MOTION M.1302.5176 Servo Drive

Technical Specifications

Model：M.1302.5176 Brand：DANAHER MOTION Product Type: M series high performance digital servo amplifier for industrial motion control

Drive Feature: Control mode: Position / Speed / Torque control Command input: Pulse & direction, ±10V analog command Built-in function: Electronic cam, homing routine, S-curve acceleration PWM switching frequency: 10kHz

Electrical Parameters: Input voltage: 230VAC single phase Continuous output current: 14A Peak output current: 28A Control supply: 24VDC

Mechanical & Structure: Housing: Reinforced metal sheet enclosure Mounting: DIN rail mounting Cooling: Forced air cooling Protection class: IP20

Environmental: Operating temperature: 0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved Weight: Approx 2.4kg

System compatibility

M.1302.5176 belongs to DANAHER MOTION M series servo drive family. Compatible with DANAHER MOTION brushless synchronous servo motors and mainstream PLC motion controllers. Suitable for heavy packaging equipment,material handling systems and CNC machine single-axis motion applications.

Function

M.1302.5176 is digital servo amplifier manufactured by DANAHER MOTION. It receives motion command signals from upper controller and outputs high regulated drive power to servo motor. Closed-loop control is realized through encoder feedback to achieve high-precision positioning and stable speed regulation. Built-in motion functions simplify machine programming and commissioning for heavy load applications.

Installation

Follow lockout/tagout safety procedure before installation. Mount M.1302.5176 on DIN rail inside electrical cabinet. Connect power cable, motor cable and encoder cable strictly follow DANAHER MOTION M series wiring manual. Complete motor auto-tuning and motion test during commissioning.

Interface

AC power terminals, motor output terminals, encoder port, digital I/O terminals, RS232 communication port, status LED indicator for DANAHER MOTION M.1302.5176.

Feature

Original DANAHER MOTION M.1302.5176 high-power digital servo drive,multiple control modes,high dynamic response,DIN rail installation,forced air cooling,UL & CE certified. This spare unit is used for heavy-duty automation equipment axis control,motion system maintenance and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage,undervoltage,overcurrent and overtemperature faults. Motor no rotation: Check power wiring,encoder connection and drive enable signal. Positioning deviation: Re-tune servo gain,inspect encoder signal and mechanical backlash. Abnormal vibration: Adjust servo parameters,check motor and coupling alignment.

Product Brief

M.1302.5176 is DANAHER MOTION M series high power digital servo amplifier,supports multi-mode control,matched with Danaher brushless servo motors,classic spare part for heavy-duty CNC and industrial automation motion system.
