DEIF ENERCONGCP3 GPC‑3 Generator Paralleling Controller

Technical Specifications

Model:ENERCONGCP3(GPC‑3)

Brand:DEIF

System compatibility:GPC‑3 series generator paralleling controller,supports AOP‑1 local panel and AOP‑2 remote CAN‑bus panels,uses M‑Logic configuration tool for custom application logic;communicates with upper monitoring system via Modbus‑RTU

Function:All‑in‑one generator parallel control unit,executes generator start‑stop,breaker synchronisation,active/reactive load‑sharing;integrates multi‑level electrical protection for over‑voltage,under‑voltage,over‑current,frequency deviation;LCD local display,alarm handling and fault event storage;supports custom logic programming via M‑Logic software,expandable by AOP‑1/AOP‑2 auxiliary operator panels

Installation:Front panel cut‑out mounting for switchgear cabinet

Interface:

‑CAN‑bus interface for AOP‑2 remote panels

‑D‑SUB9 service port for M‑Logic configuration

‑Terminal blocks for CT/PT measuring input,digital I/O,relay output

‑Dedicated port for AOP‑1 local short‑cable panel

Display:Backlit LCD display

Operation element:Membrane function push‑buttons

Circuit feature:Built‑in flash memory for logic parameters,hardware watchdog,surge suppression for measuring inputs,communication channel galvanic isolation

Feature:Compact panel‑mount controller,land‑based power station oriented,flexible custom logic development,different AOP panels for local or remote operation

Diagnostic:Front‑panel LED reflects power supply,operating status and fault alarms;fault codes can be read on LCD or transmitted over Modbus‑RTU

Power supply:24VDC external power supply

Protection class:Front panel IP40

Horizontal operating temperature:‑25℃ ~ +70℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:0.65kg

Dimensions:240mm ×140mm ×45mm

Certification:CE

Built‑in function

ENERCONGCP3(GPC‑3) is DEIF multifunctional generator paralleling controller. It completes automatic genset synchronisation,load distribution and electrical protection. M‑Logic tool supports custom logic development according to project demands. AOP‑1/AOP‑2 auxiliary panels realize local or remote operation. Widely used for land‑based generator parallel power‑station automation.

Product Brief

ENERCONGCP3(GPC‑3) belongs to DEIF GPC‑3 series power‑control‑system spare‑part family,all‑in‑one generator paralleling controller. Supports AOP‑1 and AOP‑2 auxiliary panels and M‑Logic custom programming. Widely applied for power‑station equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
