Emerson 02‑766070 DeltaV System PCB Circuit Board

Technical Specifications

Model：02‑766070

Brand：Emerson

Product Type：DeltaV System PCB Circuit Board

Applicable System：Emerson DeltaV distributed control system

Supply Voltage：24VDC auxiliary DC power input

Interface：Backplane bus connector, multi‑pin signal terminal interface

Common Revision：Multiple hardware revisions available

Status Indicator：On‑board LED for power supply, communication and fault diagnostic status

Built‑in Function：System bus signal transmission, signal conditioning processing, channel status monitoring, fault signal feedback to DeltaV host controller; supports hot‑swap operation under specified system conditions

Working Temperature：0℃ ~ +60℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Card cage slot‑in installation

Weight：0.44kg

Product Brief:

02‑766070 is legacy PCB circuit board manufactured by Emerson, it is a field‑replaceable spare component for DeltaV distributed control system. It undertakes system bus signal transmission and signal conditioning processing, monitors channel running status and feeds back fault information to the host controller. It supports hot‑swap replacement under specified power‑on conditions, non‑sparking field circuits must be de‑energized before plug‑and‑unplug operation. On‑board LED provides visual diagnosis for power, communication and fault state. This is EOL discontinued spare part,widely used for maintenance and renovation of legacy DeltaV DCS system. Please confirm hardware revision and system compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
