Emerson 02‑766400 DeltaV System PCB Circuit Board

Technical Specifications

Model：02‑766400

Brand：Emerson

Product Type：DeltaV System PCB Circuit Board

Applicable System：Emerson DeltaV distributed control system

Supply Voltage：24VDC auxiliary DC power input

Interface：Backplane bus connector, multi‑pin signal terminal interface

Common Revision：Multiple hardware revisions available

Status Indicator：On‑board LED for power supply, communication and fault diagnostic status

Built‑in Function：Backplane bus data interaction, signal conditioning and filtering, channel signal acquisition, fault diagnosis and status feedback to DeltaV host controller, support module hot‑swap under specified system conditions

Working Temperature：0℃ ~ +60℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Card cage slot‑in installation

Weight：0.46kg

Product Brief:

02‑766400 is legacy PCB circuit board manufactured by Emerson, it is a field‑replaceable spare component for DeltaV distributed control system. It completes backplane bus data interaction and signal filtering conditioning, collects channel signal status and feeds diagnostic information back to host controller. On‑board LED provides visual diagnosis for power, communication and fault state. This is EOL discontinued spare part,widely used for maintenance and renovation of legacy DeltaV DCS system. Please confirm hardware revision, firmware version and system compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
