Emerson 12P0555X132 Digital Output Module

Technical Specifications

Model：12P0555X132

Brand：Emerson

Product Type：Digital Output Module

Applicable System：Emerson DeltaV DCS system, petrochemical and thermal power plant control cabinet

Supply Voltage：24VDC

Interface：DeltaV system backplane connector, field control signal terminal block

Common Revision：Multiple hardware revisions available

Status Indicator：On‑board LED for power supply, channel output status and fault diagnostic status

Built‑in Function：Controller switch command output, field relay and actuator driving, output channel short‑circuit protection, channel status feedback, fault self‑diagnosis

Working Temperature：0℃ ~ +60℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：DeltaV rack slot‑in installation

Weight：0.59kg

Product Brief:

12P0555X132 is legacy 8‑channel digital output module for Emerson DeltaV DCS system. It receives control commands from DeltaV main controller via rack backplane bus, outputs 24VDC switch signals to drive field relays, solenoid valves and other executing devices. Each channel is equipped with short‑circuit protection function. On‑board LED provides visual diagnosis for power, channel output and fault state. This is EOL discontinued spare part,widely used for maintenance and renovation of petrochemical and thermal power plant DeltaV DCS equipment. Please confirm hardware revision and rack compatibility before purchase. Strict ESD anti‑static protection shall be followed during installation and replacement.
