Emerson 1B30016H01 Ovation I/O Base Unit

Technical Specifications

Model:1B30016H01

Brand:Emerson

Product Type:I/O Base Unit

Applicable System:Emerson Ovation distributed control system, thermal power plant DCS control cabinet

Installation:DIN‑rail mounting inside Ovation cabinet

Backplane:Internal bus signal transmission for matched electronic module

Terminal:Field signal wiring terminals

Common Revision:Multiple hardware revisions available

Built‑in Function:Electronic module mechanical support, backplane bus signal transmission, field signal wiring access, signal wiring isolation, module positioning and locking

Working Temperature:0℃ ~ +60℃

Storage Temperature:-20℃ ~ +70℃

Protection Class:IP20

Weight:0.52kg

Product Brief:

1B30016H01 is Emerson Ovation dedicated I/O base unit. It serves as the mounting carrier and terminal base for Ovation series I/O electronic modules. It provides mechanical positioning and locking for the upper‑plug electronic module, realizes electrical connection between module and system backplane bus, and reserves field signal wiring terminals for on‑site cable connection. The base completes signal isolation and wiring transition between field side and system side. It adopts DIN‑rail installation mode, easy for cabinet layout and module replacement. This is EOL discontinued spare part,widely used for maintenance and renovation of thermal power plant Ovation DCS system. Please confirm matching electronic module model before purchase. Strict ESD anti‑static protection shall be followed during installation and replacement.
