Emerson Rosemount 396P‑02‑10‑55 pH / ORP Sensor

Technical Specifications

Model：396P‑02‑10‑55

Brand：Emerson Rosemount

Product Type：pH/ORP analytical sensor

Applicable System：Process analytical transmitters 54,56,1055,1056 series, wastewater, papermaking, chemical industry on‑line water quality monitoring system

Process Medium：Suspension‑containing sewage, pulp, corrosive mixed medium

Cable：Integrated 4.6m cable, no built‑in preamplifier

Measurement Range：0‑14 pH

Temperature Compensation：Pt100 temperature compensation

Max process pressure：10.34 bar

Max process temperature：100℃

Housing Material：Polypropylene

Interface：Sensor cable direct output, match Rosemount analytical transmitters

Protection Class：IP65

Mounting：Insert / immersion installation by NPT thread

Weight：0.75kg

Product Brief:

396P‑02‑10‑55 is immersion‑insertion pH/ORP sensor manufactured by Emerson Rosemount. It adopts proprietary TUpH large‑area reference junction technology, effectively resists contamination and medium poisoning, suitable for harsh working conditions with high solid‑content, dirty and abrasive medium such as wastewater treatment and papermaking flow box. Equipped with Pt100 temperature compensation, ensures accurate pH measurement under variable temperature conditions. Polypropylene housing provides good chemical corrosion resistance. Matches with Emerson series analytical transmitters for on‑line continuous water quality analysis. This is field‑replaceable analytical spare part, widely used for on‑site instrument maintenance. Please confirm transmitter model and medium working condition before purchase. Strict anti‑pollution protection shall be performed during storage and installation, avoid damaging glass measuring diaphragm.
