MOOG 600055100LG Machinery Protection Output Module

Technical Specifications

Model:600055100LG

Brand:MOOG

Product type:Machinery Protection Output Module

Power supply:24V DC

Communication interface:Digital bus

Function:Receive protection judgment signal,alarm relay output,trip interlock output,status feedback to system

Dimension:245mm160mm35mm

Weight:1.3kg

Operating temperature:-20℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

600055100LG belongs to MOOG machinery protection system,widely used in steam turbine,generator and other rotating machinery monitoring systems,executes alarm and trip commands sent by the main CPU module.It is spare part for legacy power plant control equipment overhaul.

Function

600055100LG is dedicated output module for mechanical protection.It receives command signals from the processor module,drives on-board relays to generate local alarm and equipment trip signals,sends output status feedback back to the control system.

Installation

Install module in standard rack chassis,tighten mounting screws.Connect 24V DC power,system bus and field trip/alarm wiring.Complete wiring inspection and function test before commissioning.Take anti-static protection during handling.

Interface

‑DC power terminal

‑Digital bus communication port

‑Relay alarm & trip output terminals

‑Module identification label

Feature

MOOG high reliable machinery protection relay output module.Typical faults:relay contact burnout,bus communication failure,output channel failure,circuit aging.Inspect relay contact status and bus connection before replacement.

Diagnostic

Fault phenomenon:no alarm or trip output,status feedback abnormal,channel offline.Check 24V power supply,bus cable,terminal wiring and relay contacts.

Product Brief

600055100LG is MOOG machinery protection output module,used for alarm and safety trip interlock output in rotating machinery monitoring system,applied to power plant equipment renovation and maintenance.Mainly used for replacement of industrial protection output components.Anti-static protection must be followed during handling.
