MOOG A02KO4F0HNY Digital Servo Drive

Technical Specifications

Model:A02KO4F0HNY

Brand:MOOG

Product type:Digital Servo Drive

Power supply:380V AC

Communication interface:EtherCAT / digital bus

Function:High-speed closed-loop motor control,position,speed and torque regulation,single-axis high dynamic motion control

Dimension:280mm185mm75mm

Weight:3.2kg

Operating temperature:-20℃ ~ +60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

A02KO4F0HNY belongs to MOOG motion control drive shturl.cc applies to dynamic hydraulic test bench,simulation vibration rig and precision forming machinery,widely used in high-precision single-axis motion control system.It is spare part for legacy automation equipment overhaul.

Function

A02KO4F0HNY is high performance digital servo drive.It realizes real-time closed-loop control of servo motor,supports position,velocity and torque working mode,executes high response single-axis movement for industrial test platform.

Installation

Mount drive in standard electrical cabinet,tighten mounting screws.Connect 380V AC power,motor cable and communication bus.Complete parameter configuration and function test before commissioning.Take anti-static protection during handling.

Interface

‑AC power terminal

‑Motor encoder & power port

‑Digital bus communication port

‑Status indicator & module identification label

Feature

MOOG high reliable digital servo drive.Typical faults:power board damage,communication interruption,encoder signal loss,IGBT aging.Inspect power supply and bus communication before replacement.

Diagnostic

Fault phenomenon:no power,axis alarm,communication offline,motor abnormal operation.Check AC power,encoder wiring,bus connection and drive firmware status.

Product Brief

A02KO4F0HNY is MOOG digital servo drive with high dynamic single-axis motion control capability,used for industrial dynamic test and automation equipment,suitable for automation system maintenance and replacement.Anti-static protection must be followed during handling.
