NI 960903-02 Single-Board RIO Controller

Technical Specifications

Model:960903-02

Brand:NI

Part No:960903-02

Product type:Single-Board RIO Embedded Controller

CPU:Intel Atom Dual-Core

Clock:1.33GHz

FPGA:Xilinx Artix-7 XC7A75T

Memory:1GB DRAM,4GB onboard storage

Bus:RMC mezzanine connector,PCIe internal bus

Form Factor:OEM single board

Power supply:9~30V DC,max 28W

Dimension:100mm160mm17mm

Weight:0.45kg

Interface:2×Ethernet port,1×RS232 serial port,1×CAN port,RMC connector,96×3.3V digital I/O

Operating temperature:0℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5~90% non-condensing

Certification:CE

System compatibility

960903-02 belongs to NI sbRIO CompactRIO series embedded controller.It can work with C Series I/O modules,used widely in industrial control,test & measurement,automation and semiconductor equipment.It is spare part for legacy equipment overhaul.

Function

960903-02 is an OEM CompactRIO single-board RIO controller,integrated real-time processor and reconfigurable Artix-7 FPGA.It supports LabVIEW Real-Time and LabVIEW FPGA,executes control logic and data acquisition.It communicates with peripheral modules via Ethernet,RS232,CAN and digital I/O,with onboard watchdog timer for reliable embedded control.

Installation

Mount 960903-02 inside OEM equipment chassis,lock the board.Connect power cable,network cable,serial cable and RMC I/O modules.Take ESD protection before power-on.

Interface

‑Dual Ethernet port

‑RS232 serial port

‑CAN bus port

‑RMC mezzanine connector

‑96 channel 3.3V digital I/O

‑Watchdog timer

‑+9~30V DC power terminal

Feature

960903-02 classic NI sbRIO embedded board.Typical faults:gold finger oxidation,FPGA chip failure,serial transceiver damage,battery leakage.Clean gold finger and test board before replacement.

Diagnostic

Fault phenomenon:no power on,boot failure,network communication error,serial port no data output,CAN bus failure.Check power supply,clean gold finger,test I/O and communication circuit.

Product Brief

960903-02 is NI sbRIO embedded controller with 1.33GHz dual-core Atom CPU and Artix-7 XC7A75T FPGA,1GB DRAM,4GB storage,equipped with dual Ethernet,RS232,CAN and 96 digital I/O.Mainly used for maintenance and replacement of old industrial test & control equipment.ESD protection must be followed during handling.
