NI PCI-1200 PCI Bus Multifunction 12-bit DAQ Board

Technical Specifications

Model:PCI-1200

Brand:NI

Part No:PCI-1200

Product type:PCI Bus Multifunction I/O DAQ Board

ADC:12-bit successive approximation ADC

Analog Input:16 single-ended /8 differential channels,max 100kS/s

Input voltage ranges:±10V,±5V,±2.5V,0~10V

Analog Output:2 channels,12-bit DAC,0~10V / ±5V

Digital I/O:24 lines 5V TTL/CMOS bidirectional

Counter/Timer:3×16-bit counter,max 8MHz input

Connector:68-pin I/O connector

Bus:PCI

Dimension:220mm120mm20mm

Weight:0.23kg

Operating temperature:0℃ ~ +55℃

Storage temperature:-20℃ ~ +70℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

PCI-1200 belongs to NI legacy PCI DAQ platform.It supports Traditional NI-DAQ driver and older LabVIEW versions,works with standard PCI industrial PCs,widely used for sensor signal sampling,voltage output and pulse timing measurement in laboratory test and industrial monitoring systems.It is spare part for legacy test equipment overhaul.

Function

PCI-1200 is low-cost multifunction PCI DAQ board integrating analog input,analog output,digital I/O and counter timers.Programmable gain for analog channels,hardware trigger supports synchronized sampling,used for signal measurement,test stimulus generation and digital switch control.

Installation

Insert PCI-1200 into computer PCI slot and fasten bracket.Connect 68pin signal cable to terminal block.Install legacy Traditional NI-DAQ driver.Take ESD protection before installation.

Interface

‑68-pin multi I/O connector

‑PCI gold finger edge connector

‑Board status indicator

Feature

PCI-1200 classic NI PCI multifunction DAQ board.Typical faults:gold finger oxidation,ADC/DAC drift,counter circuit failure.Inspect edge connector and channel reading before replacement.

Diagnostic

Fault phenomenon:no analog reading,unstable AO,DIO no response.Check PCI slot contact,68pin wiring,legacy DAQ driver and board calibration status.

Product Brief

PCI-1200 is NI PCI bus 12-bit multifunction DAQ board with 16SE/8DI analog input,2 analog output,24 TTL DIO and triple 16-bit counters,suitable for laboratory signal acquisition and renovation of old industrial monitoring and test systems.Mainly used for maintenance and replacement of old test equipment.ESD protection must be followed during handling.
