ProSoft ILX34-MBS485 POINT I/O Modbus RTU RS485 Communication Module

Technical Specifications

Model:ILX34-MBS485

Brand:ProSoft

Product type:POINT I/O Modbus Serial Communication Module

Power supply:10-28.8VDC,75mA @5VDC via Pointbus

Communication:Modbus RTU / ASCII,RS485

Weight:0.12kg

Operating temperature:-25℃ ~ +70℃

Dimension:56mm12mm75.5mm

Certification:CE,UL

System compatibility

ILX34-MBS485 belongs to ProSoft POINT I/O series module.It is compatible with Rockwell 1734 POINT I/O backplane and CompactLogix L1 controllers,suitable for connecting Modbus RTU field instruments into Logix control system.

Function

It can be configured as Modbus master or slave,realizes bidirectional real-time data mapping between Rockwell POINT I/O system and RS485 Modbus devices.Supports up to 1000 words of data storage and full set of Modbus function codes.

Installation

DIN rail mounting,install module on 1734 POINT I/O backplane with wiring base,connect RS485 bus wiring,configure parameters via ProSoft Configuration Builder,check LED indicators after power on.

Interface

RS485 serial terminal,POINT I/O backplane connector,power terminal,module status,network status,TXD and RXD LED indicators.

Feature

Compact slim POINT I/O form factor,supports baud rate from 110bps to 115.2kbps,long transmission distance up to 1219 meters,diagnostic tags available inside controller,stable operation in industrial cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify RS485 wiring,terminal resistor,station address and baud rate;data abnormal:check module configuration and register mapping.

Product Brief

ILX34-MBS485 is ProSoft POINT I/O Modbus RS485 serial module.It integrates Modbus RTU field sensors,transmitters and meters into Rockwell CompactLogix / POINT I/O control system,for industrial automation system maintenance and transformation.
