ProSoft ILX69-PBS CompactLogix PROFIBUS DP V1 Slave In-Chassis Module

Technical Specifications

Model:ILX69-PBS

Brand:ProSoft

Product type:CompactLogix In-Chassis PROFIBUS Slave Module

Power supply:Supplied via 1769 backplane,5V @570mA max

Communication:PROFIBUS DP V0/V1,baud rate up to 12Mbps

Weight:0.152kg

Operating temperature:0℃ ~ +60℃

Dimension:131.6mm92.1mm39.3mm

Certification:CE,UL,PI Certified

System compatibility

ILX69-PBS belongs to ProSoft 1769 series module.It plugs into Rockwell CompactLogix and MicroLogix 1769 chassis,enables Logix controller to work as PROFIBUS DP slave device,suitable for connecting CompactLogix system to existing PROFIBUS DP master networks in factory automation renovation.

Function

It acts as PROFIBUS DP V1 slave,supports cyclic I/O data exchange and acyclic DPV1 messaging,max 244 bytes input and 244 bytes output cyclic data,acyclic read/write up to 240 bytes. PROFIBUS master can directly exchange I/O data with CompactLogix controller via backplane I/O mapping.

Installation

Insert module into 1769 CompactLogix chassis within 2 slots of power supply,wire PROFIBUS RS485 bus,set slave address via rotary switch,configure I/O mapping in Studio 5000 / RSLogix5000,verify LED indicators after power-up.

Interface

PROFIBUS RS485 terminal port,1*10/100Mbps Ethernet RJ45 diagnostic port,1769 backplane connector,multi-color run and fault LED indicators.

Feature

Standard 1769 single slot design,galvanic isolated PROFIBUS interface,web page remote diagnostics,fully compatible with Studio5000 AOP profile,PI certified,supports DPV1 alarm and acyclic data access.

Diagnostic

Check module run and fault LED;communication failure:verify PROFIBUS bus cable,terminal resistor,slave address and baud rate;data abnormal:check I/O mapping and studio5000 module configuration.

Product Brief

ILX69-PBS is ProSoft 1769 in-chassis PROFIBUS DP V1 slave module.It makes CompactLogix/MicroLogix PLC become PROFIBUS DP slave node and communicate with PROFIBUS DP master controllers,for industrial automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and renovation.
