ProSoft MVI46-103M SLC500 IEC 103 Master Module

Technical Specifications

Model:MVI46-103M

Brand:ProSoft

Product type:SLC500 In-Chassis IEC 103 Master Communication Module

Power supply:Supplied via SLC500 backplane,800mA @5VDC

Communication:IEC 60870-5-103,RS232/RS485 serial interface

Weight:0.27kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard SLC500 single slot module,120mm87mm32mm

Certification:CE,UL

System compatibility

MVI46-103M belongs to ProSoft MVI46 series module.It plugs directly into Rockwell SLC500 rack,enables SLC500 PLC to communicate with IEC103 compatible relay and protection devices in power substation systems,suitable for power plant and substation automation upgrade and spare replacement.

Function

It acts as IEC 60870-5-103 master station,realizes data acquisition from protection relays and fault recording devices,supports event alarm,measuring value reading and device status monitoring.Data is mapped to SLC500 controller memory via backplane for further processing.

Installation

Insert module into SLC500 chassis backplane,connect RS485/RS232 serial cable to protection devices,configure IEC103 station parameters and data mapping via ProSoft Configuration Builder,download project through RSLinx,check LED indicators after power-up.

Interface

2*RJ45 serial application ports,RJ45 configuration port,SLC500 backplane connector,module status,application and serial communication LED indicators.

Feature

Single slot SLC500 chassis design,optimized for power substation relay communication,supports multiple IEC103 slave devices,event timestamp recording,web diagnostic interface,stable operation in power cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify serial wiring,terminal resistance,station address and baud rate;data abnormal:check IEC103 parameter configuration and data mapping table.

Product Brief

MVI46-103M is ProSoft MVI46 series IEC 103 master communication module for SLC500 rack.It connects Rockwell SLC500 controller with IEC103 substation protection relays,for power industrial automation system maintenance and transformation.
