ProSoft MVI46-PDPMV1 SLC500 PB Master Module

Technical Specifications

Model:MVI46-PDPMV1

Brand:ProSoft

Product type:SLC500 In-Chassis PROFIBUS DPV1 Master Module

Power supply:Supplied via SLC500 backplane,800mA @5VDC

Communication:PROFIBUS DP V0/V1,max baud rate 12Mbps

Weight:0.27kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard SLC500 single slot module,120mm87mm32mm

Certification:CE,UL

System compatibility

MVI46-PDPMV1 belongs to ProSoft MVI46 series module.It plugs directly into Rockwell SLC500 rack,compatible with SLC 5/02 and above processors with M0/M1 file capability,suitable for connecting SLC500 PLC to PROFIBUS DP field devices,legacy factory automation system renovation and spare replacement.

Function

It works as PROFIBUS DP V1 master,supports cyclic I/O data exchange and acyclic DPV1 parameter access,supports up to 125 PROFIBUS slave nodes.Data is mapped to SLC500 controller memory via backplane,supports GSD file import for slave device configuration.

Installation

Insert module into SLC500 chassis backplane,connect PROFIBUS RS485 bus cable,configure network and slave parameters via ProSoft Configuration Builder,download project through RSLinx,check LED indicators after power-up.

Interface

PROFIBUS DB9 network port,RJ45 configuration serial port,SLC500 backplane connector,module status,network and communication LED indicators.

Feature

Single slot SLC500 chassis design,supports PROFIBUS DPV1 acyclic messaging,galvanic isolation for PROFIBUS interface,DTM configuration tool,web diagnostic interface,stable operation in industrial cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify PROFIBUS bus cable,terminal resistor,slave address and baud rate;data abnormal:check GSD configuration and I/O mapping table.

Product Brief

MVI46-PDPMV1 is ProSoft MVI46 series PROFIBUS DPV1 master communication module for SLC500 rack.It connects Rockwell SLC500 controller with PROFIBUS DP field slaves,for industrial automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and renovation.
