ProSoft MVI56-BAS CLX BASIC Module

Technical Specifications

Model:MVI56-BAS

Brand:ProSoft

Product type:ControlLogix In-Chassis BASIC Programmable Module

Power supply:Supplied via 1756 backplane,800mA @5.1VDC,3mA @24VDC

Communication:DH485,ASCII,DF1 serial communication

Weight:0.29kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard 1756 single slot module,120mm87mm32mm

Certification:CE,UL

System compatibility

MVI56-BAS belongs to ProSoft MVI56 series module.It plugs directly into Rockwell ControlLogix 1756 rack,designed to migrate legacy BASIC programs to ControlLogix platform,suitable for custom serial device interface development and spare replacement.

Function

It supports BASIC-52 programming language,users can compile custom logic for data processing and serial communication.BASIC programs stored on compact flash card for backup and auto-run on power-up.Supports DH485,ASCII and DF1 communication modes,realizes bidirectional data exchange with ControlLogix controller via backplane.

Installation

Insert module into ControlLogix chassis backplane,connect serial wiring,write and download BASIC program via configuration tool,store program to CF card,download project through RSLinx,check LED indicators after power-up.

Interface

DH485 port,2*RJ45 serial application ports,CF card slot,1756 backplane connector,alpha-numeric display,module status and communication LED indicators.

Feature

Single slot 1756 chassis design,onboard BASIC runtime engine,compact flash for program storage,flexible serial ports for barcode scanners,scales and modems,reduces controller logic load,stable operation in industrial cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify serial wiring,terminal resistance,station address and baud rate;data abnormal:check BASIC program logic and CF card program file.

Product Brief

MVI56-BAS is ProSoft MVI56 series BASIC programmable communication module for ControlLogix rack.It provides custom programming capability to connect various serial devices,for industrial automation system maintenance and transformation.
