ProSoft MVI56E-MNET/MNETXT CLX MNET Module

Technical Specifications

Model:MVI56E-MNET/MNETXT

Brand:ProSoft

Product type:ControlLogix In-Chassis Enhanced Modbus TCP Communication Module

Power supply:Supplied via 1756 backplane,800mA @5.1VDC,3mA @24VDC

Communication:Modbus TCP/IP,10/100Mbps Ethernet

Weight:0.29kg

Operating temperature:0℃ ~ +60℃(MNET); -25℃ ~ +70℃(MNETXT)

Dimension:Standard 1756 single slot module,120mm87mm32mm

Certification:CE,UL

System compatibility

MVI56E-MNET/MNETXT belongs to ProSoft MVI56E enhanced series module.It plugs directly into Rockwell ControlLogix 1756 rack,MNETXT version supports Logix-XT extreme environment platform,compatible with ControlLogix PAC controllers,backward compatible with legacy MVI56-MNET.Suitable for connecting Modbus TCP ethernet field instruments,industrial system renovation and spare replacement.

Function

It works as Modbus TCP client and server at the same time,supports multiple concurrent TCP connections.It can read and write data with remote Modbus TCP devices,and respond to Modbus TCP client requests.Supports up to 5000 16-bit user registers for data exchange.Data mapped to ControlLogix controller memory via backplane.MNETXT adopts conformal coating for dust and corrosion protection under extreme temperature sites.

Installation

Insert module into ControlLogix chassis backplane,connect Ethernet cable,set IP address and configure Modbus command list via ProSoft Configuration Builder,import AOI into Studio5000,download project through RSLinx,check LED indicators after power-up.

Interface

1*10/100Mbps Ethernet RJ45 port,CF card slot,1756 backplane connector,alpha-numeric display,module status,network and communication LED indicators.

Feature

Single slot 1756 chassis design,auto crossover ethernet detection,web diagnostic interface,CIPconnect remote diagnostic support,supports RIUP hot swap,CF card for configuration backup.MNETXT with conformal coating and wide temperature range,stable operation in harsh industrial cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify Ethernet cable,IP address and network route;data abnormal:check Modbus TCP command list and register mapping table.

Product Brief

MVI56E-MNET/MNETXT is ProSoft MVI56E series enhanced Modbus TCP ethernet communication module for ControlLogix rack.It realizes bidirectional Modbus TCP data exchange between ControlLogix and third-party ethernet devices,MNETXT variant designed for wide temperature and corrosive industrial applications,for industrial automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
