ProSoft PLX51-PBM PROFIBUS DP Master/Slave Gateway

Technical Specifications

Model:PLX51-PBM

Brand:ProSoft

Product type:PROFIBUS DP DPV0/DPV1 Master/Slave to EtherNet/IP / Modbus Multi-protocol Gateway

Power supply:10~36VDC,85mA@24VDC,max 2.04W

Ethernet:210/100Mbps RJ45,support DLR(Device Level Ring)

PROFIBUS DP:DPV0/DPV1,configurable as Master or Slave

PROFIBUS baud rate:9.6k,19.2k,45.45k,93.75k,187.5k,500k,1.5M,3M,6M,12Mbps

Cyclic I/O data:Input 1536 bytes,Output 1536 bytes

Supported upper protocols:EtherNet/IP,Modbus TCP,Modbus RTU(RS232/RS485)

Weight:0.42kg

Operating temperature:-20℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:149mm34mm*116mm

Certification:CE,UL,Class I Division2

System compatibility

PLX51-PBM belongs to ProSoft PLX51 series PROFIBUS DP multi-mode gateway.

Realize data exchange between PROFIBUS DP field devices and Rockwell Logix EtherNet/IP controllers.

Compatible with ControlLogix,CompactLogix,Siemens PROFIBUS DP slave devices,ET200 series remote I/O.

Support FactoryTalk View and Modbus SCADA system.

Suitable for automotive production line,water treatment,petrochemical,power plant cross-brand PLC network integration and spare replacement.

Function

Support PROFIBUS DP DPV0/DPV1,switch between Master or Slave working mode.

Dual Ethernet ports,support DLR ring network topology,also work as embedded network switch.

Bidirectional data conversion between PROFIBUS DP and EtherNet/IP / Modbus TCP / Modbus RTU.

EtherNet/IP direct-to-tag function,data directly written into Logix controller tags,dynamic AOI auto generation.

Built-in PROFIBUS device discovery and DP packet capture tool,convenient for on-site commissioning and troubleshooting.

Support FDT/DTM,realize parameter configuration and asset management for PROFIBUS field instruments.

Web server for module status view,diagnostic statistics and parameter configuration.

Configuration via PLX50 Configuration Utility.

Installation

Mount gateway on DIN rail,connect 10~36VDC power supply and earth terminal.

Connect PROFIBUS DP bus cable to PROFIBUS terminal,set terminal resistor as required.

Connect dual RJ45 ports to EtherNet/IP or Modbus TCP network,configure DLR if needed.

Select PROFIBUS master/slave mode,set baud rate and I/O mapping via PLX50 Configuration Utility.

Check LED indicators after power-on.

Interface

2*10/100Mbps Ethernet RJ45,PROFIBUS DP terminal,power & earth terminal,LED indicators:PWR,RUN,BF,AUX.

Feature

DIN rail installation,compact structure for industrial cabinet.

Dual Ethernet with DLR ring function,improve network redundancy reliability.

One module can be set as PROFIBUS master or slave,flexible project selection.

Large cyclic I/O data capacity,support high-volume PROFIBUS remote I/O data transmission.

Built-in bus diagnostic and packet capture,reduce PROFIBUS network debugging difficulty.

Dynamic AOI for Rockwell Logix,shorten project programming cycle.

Shock and vibration resistant design,stable long-term operation in industrial cabinet.

Diagnostic

Check PWR and BUS LED;communication failure:verify PROFIBUS wiring,bus terminal resistor and baud rate;data abnormal:check I/O mapping,slave station configuration and Ethernet DLR status.

Product Brief

PLX51-PBM is ProSoft PLX51 series PROFIBUS DP multi-mode protocol gateway.

It realizes data interconnection between PROFIBUS DP field bus and Rockwell EtherNet/IP or Modbus control system,supports DPV0/DPV1 master/slave switching,widely used for cross-brand automation system integration transformation.
