RELIANCE 0-54339-14 Memory Logic Board

Technical Specifications

Model:0-54339-14（5433914）

Brand:RELIANCE

Product type:Digital Memory & Logic PCB Board

Weight:0.43kg

Dimension:220mm115mm25mm

Operating temperature:0℃ ~ 60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~85%,non-condensing

Certification:CE

System compatibility

0-54339-14 belongs to RELIANCE CardPak series memory logic board.

Installed into CardPak DC drive rack,works with 5138116 main controller board,5186518 current loop driver board,563052 auxiliary power supply board and other plug-in boards.

Responsible for digital parameter saving and logic coordination for CardPak digital DC drive system.

Compatible with AutoMax control system for heavy industry production line.

Commonly used for old DC drive equipment maintenance and spare replacement.

Function

0-54339-14 is dedicated memory logic PCB board for RELIANCE CardPak digital DC drive system.

Store drive configuration parameters,loop gain,protection threshold,preset speed and commissioning data.

Process digital logic signals and coordinate analog regulator boards for compound closed-loop control.

Support onsite parameter read and write for drive commissioning and modification.

Detect memory data anomaly and trigger fault alarm signal.

Communicate with interface board to upload running status and parameter information.

Onboard test points for logic signal inspection and parameter verification.

Installation

Power off the whole CardPak drive rack and cut main power supply.

Insert 0-54339-14 board into designated slot of drive rack.

Fasten fixing screws.

Connect backplane edge connector and logic signal wiring.

Separate digital signal cable and high voltage power cable.

Power on system,load and verify drive configuration parameters.

Test logic interlock and data retention after power cycle.

Interface

CardPak backplane edge connector,digital logic signal terminal,parameter communication port,test measurement points,status and fault LED indicators.

Feature

RELIANCE 0-54339-14,CardPak digital memory and logic printed circuit board.

Non-volatile storage of all drive commissioning parameters.

Digital logic coordination for analog regulator hardware loop.

Data corruption detection to prevent drive operation with wrong parameters.

Multiple test points for convenient maintenance and onsite inspection.

Standard CardPak plug-in structure,easy replacement together with other regulator boards.

Discontinued obsolete board,supply only for old automation drive system spare replacement.

Suitable for metallurgy,paper-making heavy-duty DC drive production line renovation.

Diagnostic

Parameters lost after power restart:memory chip failure;

Abnormal logic signal:backplane connector poor contact;

Cannot modify parameters:communication circuit damage;

Data error fault alarm:memory data corruption;

LED no lighting:board auxiliary power supply failure.

Product Brief

RELIANCE 0-54339-14 is CardPak memory logic board.

It stores DC drive configuration parameters and performs digital logic coordination for Reliance CardPak digital drive,widely used as spare part for heavy industry DC drive system maintenance.

Disclaimer

All parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
