RELIANCE 0-57407 Processor Module

Technical Specifications

Model:0-57407

Brand:RELIANCE

Product type:DCS5000 AutoMax Main Processor Module

Weight:0.46kg

Dimension:263mm58mm28mm

Operating temperature:0℃ ~ 60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~85%,non-condensing

Certification:CE

System compatibility

0-57407 belongs to RELIANCE AutoMax DCS5000 series main CPU processor module.

Installed into AutoMax rack,cooperates with 57045 UDC drive controller,57405 analog I/O,57406 drive control module and all digital I/O modules.

Supports DCSNet distributed network communication for multi-rack interconnection.

Can execute ladder logic,BASIC and control block programs for production line and drive system control.

Commonly used for old DCS and drive equipment maintenance and spare replacement.

Function

0-57407 is main processor for RELIANCE AutoMax DCS5000 distributed control system.

Run user control program,complete logic operation and arithmetic calculation.

Communicate with all rack I/O modules via backplane bus,collect field signal and output control command.

DCSNet network interface for data exchange between multiple AutoMax racks.

Built-in watchdog timer for system fault detection.

Store system configuration and user application program.

Upload system alarm,drive fault and process status to programming software.

Installation

Power off the whole AutoMax rack and cut main power supply.

Insert 0-57407 module into designated CPU rack slot.

Lock module retaining clips.

Connect backplane bus and DCSNet network cable.

Separate network cable and high voltage power cable to reduce interference.

Power on system,download user program and hardware configuration.

Test rack I/O scanning,DCSNet communication and program execution.

Interface

AutoMax backplane edge connector,DCSNet network port,run/fault/status LED indicators,reset switch.

Feature

RELIANCE 0-57407,AutoMax DCS5000 main processor module.

Support multiple programming languages including ladder and BASIC.

DCSNet distributed network for multi-node system expansion.

Hardware watchdog to prevent program runaway.

Multiple LED diagnostic indicators for running status and fault code viewing.

Discontinued obsolete module,supply only for old automation system spare replacement.

Suitable for metallurgy,paper-making heavy-duty distributed control system renovation.

Diagnostic

Module fault LED on:watchdog trigger or program error;

No communication with I/O modules:backplane poor contact or rack power fault;

DCSNet communication failure:network cable damage or node address conflict;

Cannot download program:programming cable fault or module hardware damage;

Program stop running:hardware interlock or fatal program error.

Product Brief

RELIANCE 0-57407 is AutoMax DCS5000 main processor module.

It executes user control program,scans rack I/O and realizes distributed DCSNet network communication,widely used as spare part for heavy industry automation system maintenance.

Disclaimer

All parameters are for reference only and not for quotation basis. Goods are scarce and will be powered on for inspection before shipment. Overseas delivery lead time 3-7 working days. This item is only used for equipment maintenance and retrofit.
