SEW 050-443 MOVITRAC Inverter Power Supply Board

Technical SpecificationsModel:050-443 Brand:SEW Product type:MOVITRAC Inverter Power Supply Board Weight:0.44kg Dimension:210mm135mm30mm Operating temperature:0℃ ~ 60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibility050-443 is SEW built-in auxiliary power supply board,matched for early MOVITRAC series small frequency inverter. It cooperates with main control board and IGBT power module,provides stable multi-channel low-voltage power for control circuit,opto-coupler and sampling circuit. Widely used for maintenance and spare replacement of legacy SEW MOVITRAC inverters.

Function050-443 is dedicated switching power printed circuit board for SEW MOVITRAC inverter. It takes DC bus voltage as input,converts and outputs multiple groups of stabilized DC voltages to supply power for main control logic,signal sampling and drive optocoupler. It integrates overvoltage,undervoltage and overcurrent protection circuit on power loop. Built-in rectifier,switching transformer and filter capacitor components. Dual LED indicators display board power input and output status. Suppress voltage spike and reduce ripple for stable operation of control board.

InstallationPower off the whole drive cabinet and cut main power supply. Discharge DC bus capacitor completely before operation. Install 050-443 power supply board inside MOVITRAC inverter and fasten fixing screws. Plug internal connector for DC bus input and low voltage power output. Separate high voltage DC wiring and low-voltage signal wiring. Power on the inverter,measure each channel output voltage,verify stable power supply for main control board.

InterfaceDC bus voltage input,multi-channel DC power output,auxiliary power terminal,shield grounding terminal,dual status LED indicators,filter capacitor bank.

FeatureSEW 050-443 built-in auxiliary switching power supply board. Multi-channel isolated low voltage power conversion. Integrated power loop protection circuit. Filter circuit to reduce power ripple. Reliable connector for power transmission. Dual LED visual indication for power state. Industrial PCB design for long continuous running in harsh factory environment. Discontinued obsolete board,supply only for old MOVITRAC inverter spare replacement. Suitable for conveyor,packaging machinery and small material handling equipment renovation and maintenance.

DiagnosticNo power output:switch tube damage or DC bus input missing; LED no light:input circuit failure; Voltage output unstable:aging of filter capacitor; Main board cannot start:power channel abnormal; Intermittent power dropout:connector poor contact.

Product BriefSEW 050-443 is MOVITRAC inverter auxiliary power supply board. It converts DC bus voltage into multi-group stable low voltage power for inverter internal control and sampling circuit,widely used as spare part for legacy SEW small inverter maintenance.

Disclaimer:All parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
