SEW 60A0030-5A3-4-00 MOVIDRIVE MD60A Servo Drive

Technical SpecificationsModel:60A0030-5A3-4-00 Brand:SEW Product type:MOVIDRIVE MD60A Cabinet Servo Drive Weight:2.6kg Dimension:185mm125mm170mm Rated input voltage:380~500VAC,3 phase,50/60Hz Rated power:3.0kW Rated output current:7.5A Protection class:IP20 Operating temperature:0℃ ~ 60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibility60A0030-5A3-4-00 is SEW MOVIDRIVE MD60A series cabinet-mounted servo drive. It is designed for driving three-phase asynchronous motors and synchronous servo motors,matched with operation panel and optional brake module. Widely used in conveyor,pump,fan and material handling equipment,for maintenance and spare replacement of legacy SEW drive systems.

Function60A0030-5A3-4-00 is compact standard servo drive of SEW MOVIDRIVE MD60A series. It adopts vector control algorithm,receives analog speed reference and digital run/stop signals,generates PWM three-phase output to adjust motor speed. It samples DC bus voltage,output current and power module temperature signal,realizing overcurrent,overvoltage,undervoltage and overtemperature protection. It supports local parameter setting via front panel keypad,stores operating data and fault history. Built-in basic EMC suppression circuit to reduce electromagnetic interference. Terminal block for power and signal wiring,LED indicators on front cover.

InstallationPower off the AC main power supply before installation. Mount 60A0030-5A3-4-00 vertically inside control cabinet on metal backplate with fixing screws. Keep upper and bottom clearance for heat dissipation. Separate power input cable,motor cable and low-voltage control wiring. Complete wiring according to terminal definition. Power on the drive,input motor nameplate parameters,test motor start,stop and speed adjustment function.

Interface3-phase AC power input terminal,3-phase motor output terminal,analog/digital I/O terminal,fault relay output,keypad socket,shield grounding terminal,encoder interface,LED status indicators.

FeatureSEW 60A0030-5A3-4-00 IP20 compact servo drive. Stable vector speed regulation. Integrated multi-protection functions. Built-in brake chopper. Simple terminal wiring and easy parameter commissioning. LED indicators for running and fault status. Discontinued obsolete drive,supply only for legacy MOVIDRIVE MD60A spare replacement. Suitable for logistics conveyor,packaging machinery renovation and maintenance.

DiagnosticMotor no rotation:power wiring error or parameter misconfiguration; Drive trip frequently:overload or current sampling fault; No display:input power missing; Speed unstable:analog reference interference; Intermittent shutdown:internal component aging or loose terminal contact.

Product BriefSEW 60A0030-5A3-4-00 is MOVIDRIVE MD60A 3.0kW 380~500V cabinet servo drive. It adopts vector control for asynchronous and synchronous motor speed regulation,widely used as spare part for legacy SEW conveyor drive system maintenance.

DisclaimerAll parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
