SEW 61B0150-503-4-00 MOVIDRIVE MDX61B Servo Drive

Technical SpecificationsModel:61B0150-503-4-00 Brand:SEW Product type:MOVIDRIVE MDX61B Cabinet Servo Drive Weight:15kg Dimension:200mm465mm308mm Rated input voltage:380~500VAC,3 phase,50/60Hz Rated power:15kW Rated output current:32A Protection class:IP20 Operating temperature:0℃ ~ 60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibility61B0150-503-4-00 is SEW MOVIDRIVE MDX61B series cabinet-mounted servo drive. It is designed for driving three-phase asynchronous motors and synchronous servo motors,matched with operation panel and optional brake module. Widely used in conveyor,pump,fan and material handling equipment,for maintenance and spare replacement of legacy SEW drive systems.

Function61B0150-503-4-00 is compact standard servo drive of SEW MOVIDRIVE MDX61B series. It adopts vector control algorithm,receives analog speed reference and digital run/stop signals,generates PWM three-phase output to adjust motor speed. It samples DC bus voltage,output current and power module temperature signal,realizing overcurrent,overvoltage,undervoltage and overtemperature protection. It supports local parameter setting via front panel keypad,stores operating data and fault history. Built-in STO safety function and basic EMC suppression circuit to reduce electromagnetic interference. Terminal block for power and signal wiring,LED indicators on front cover.

InstallationPower off the AC main power supply before installation. Mount 61B0150-503-4-00 vertically inside control cabinet on metal backplate with fixing screws. Keep upper and bottom clearance for heat dissipation. Separate power input cable,motor cable and low-voltage control wiring. Complete wiring according to terminal definition. Power on the drive,input motor nameplate parameters,test motor start,stop and speed adjustment function.

Interface3-phase AC power input terminal,3-phase motor output terminal,analog/digital I/O terminal,fault relay output,keypad socket,shield grounding terminal,encoder interface,LED status indicators.

FeatureSEW 61B0150-503-4-00 IP20 compact servo drive. Stable vector speed regulation. Integrated multi-protection functions. Built-in brake chopper and STO safe torque off function. Simple terminal wiring and easy parameter commissioning. LED indicators for running and fault status. Discontinued obsolete drive,supply only for legacy MOVIDRIVE MDX61B spare replacement. Suitable for logistics conveyor,packaging machinery renovation and maintenance.

DiagnosticMotor no rotation:power wiring error or parameter misconfiguration; Drive trip frequently:overload or current sampling fault; No display:input power missing; Speed unstable:analog reference interference; Intermittent shutdown:internal component aging or loose terminal contact.

Product BriefSEW 61B0150-503-4-00 is MOVIDRIVE MDX61B 15kW 380~500V cabinet servo drive. It adopts vector control for asynchronous and synchronous motor speed regulation,widely used as spare part for legacy SEW conveyor drive system maintenance.
