SIEMENS MOORE 760P11JAAGNNB7 Multi-Loop Process Controller

Technical SpecificationsModel:760P11JAAGNNB7 Brand:SIEMENS MOORE Product Type:Multi-Loop Digital PID Process Controller Power Supply:100-240V AC,47-63Hz Input Signal:4-20mA, thermocouple, RTD Output Signal:4-20mA analog output, relay alarm contact Mounting:Panel mount Operating temperature:-20℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:2.2kg Dimension:96mm192mm350mm

System compatibility760P11JAAGNNB7 belongs to SIEMENS MOORE 760 series standalone process controller. It can operate independently for closed-loop regulation, and communicate with upper DCS or HMI via serial communication port.

FunctionThis multi-loop digital PID controller realizes closed-loop control of temperature, pressure, flow and liquid level. It supports auto-tuning PID, cascade control, ratio control and feedforward control. Operators can set parameters, view real-time process values and alarm messages through front keypad and display screen, and support simple interlock logic.

InstallationCut off power before installation. Embed the controller into cabinet panel and lock mounting clips. Wire analog input, control output, alarm relay and power terminals according to wiring diagram. Complete PID tuning and communication address configuration after power on.

InterfaceRear analog input terminals, analog output terminals, relay alarm terminals, serial communication port, front panel display and operation keypad.

FeatureAuto-tuning PID algorithm, multiple control modes, built-in alarm logging, local human-machine operation, strong anti-interference for continuous plant running. Obsolete legacy spare part, used for industrial process loop controller maintenance and replacement.

DiagnosticNo display: check AC power supply and terminal wiring. Control deviation: recalibrate PID parameters, verify sensor input signal. Communication failure: inspect serial wiring, terminal resistor and station address setting.

Product BriefSIEMENS MOORE 760P11JAAGNNB7 is 760 series multi-loop digital PID process controller, widely used in petrochemical, boiler and water treatment industries for temperature, pressure and flow closed-loop control.
