Woodward 5417-032 NetCon Wiring Cable Assembly

Technical Specifications

Model:5417-032

Brand:Woodward

Product type:NetCon field wiring cable assembly

Power supply:Not required

Control function:Field signal transmission,connection between NetCon I/O modules and on-site sensors/actuators,noise suppression,shielding protection

Communication:Analog & digital field signal

Mounting:Cabinet and field wiring

Operating temperature:-40~70℃

Relative humidity:5~95% non-condensing

Weight:1.36kg

Certification:CE,UL

System compatibility

5417-032 belongs to Woodward NetCon turbine control system family,matched with NetCon I/O terminal modules and 505 series turbine controllers.Widely used in gas turbine,steam turbine and generator control cabinets.This is a discontinued legacy NetCon field wiring cable assembly for power unit maintenance spare replacement.

Function

5417-032 serves as Woodward NetCon field wiring cable assembly.It connects NetCon I/O modules and field-side sensors and actuators,transmitting analog and digital field signals for turbine monitoring and control.It adopts multi-core shielded cable structure to restrain external electromagnetic interference,guaranteeing reliable signal transmission under harsh power plant environment.It acts as field signal transmission cable for Woodward NetCon turbine control system.

Installation

Lay 5417-032 inside control cabinet and field area.Complete connector wiring according to wiring drawing.Confirm shielding grounding is properly connected before power-on.

Interface

‑D-type integrated plug connector

‑Shield ground terminal

‑Multi-core shielded signal cable

Circuit feature

Multi-core shielded twisted pair cable structure,equipped with ESD and surge suppression design.Stable field signal transmission,strong anti-interference performance for power plant cabinet environment.

Feature

5417-032 is obsolete Woodward series spare part.Typical failures include cable insulation aging,connector poor contact,shielding layer damage,signal fluctuation.Check cable body and connector pins before replacement.This cable must match corresponding Woodward NetCon system,direct substitution without inspection is not recommended.

Diagnostic

When signal loss,signal drift or intermittent disconnection occurs,the cable triggers corresponding alarm signals and sends fault message to turbine control system.

Built‑in function

Field analog/digital signal transmission,I/O module and field device interconnection,electromagnetic noise shielding,used as Woodward NetCon series wiring cable assembly spare replacement.

Product Brief

5417-032 is Woodward old turbine series NetCon field wiring cable assembly for gas/steam turbine generator sets and power automation equipment.Confirm controller and I/O module model matching before ordering.ESD protection required during handling and installation.
