Woodward 5437-076 505E Turbine Governor Controller

Technical Specifications

Model:5437-076

Brand:Woodward

Product type:505E series digital turbine governor controller

Power supply:24 Vdc

Control function:Turbine speed closed-loop regulation,load control,extraction/admission pressure control,dual actuator drive,system self-diagnosis,relay alarm output

Communication:RS232,Modbus serial port

Mounting:Panel flush mounting

Operating temperature:-20~60℃

Relative humidity:5~95% non-condensing

Weight:4.13kg

Certification:CE,UL

System compatibility

5437-076 belongs to Woodward 505E turbine control system family,applied for steam turbine,single extraction or admission turbine units.Widely used in steam turbine generator control cabinets.This is a discontinued legacy digital turbine controller for power unit maintenance spare replacement.

Function

5437-076 serves as Woodward 505E digital turbine governor.It adopts microprocessor core to realize turbine speed closed-loop control,load regulation and extraction/intake pressure control.It can drive dual hydraulic actuators to adjust steam valve,realize turbine start-up,synchronization,load shedding and overspeed protection logic.The front panel integrates two-line LCD display and membrane keyboard for local parameter setting,real-time data viewing and fault code query.It supports serial communication for remote configuration and data monitoring.

Installation

Install 5437-076 on cabinet front panel.Complete speed probe,actuator and power wiring according to wiring drawing.Check wiring and grounding before power-on.

Interface

‑RS232 communication port

‑Speed sensor input terminal

‑Dual actuator drive output terminal

‑Digital input/output terminal block

‑Front LCD and membrane keypad

Circuit feature

High precision closed-loop control circuit,equipped with ESD and surge suppression design.Stable regulation performance,strong anti-interference performance for power plant cabinet environment.

Feature

5437-076 is obsolete Woodward series spare part.Typical failures include speed measurement abnormal,valve output drift,display fault,communication interruption.Check mainboard circuit and terminal pins before replacement.This controller must match corresponding turbine actuator and speed probe,direct substitution without inspection is not recommended.

Diagnostic

When overspeed alarm,speed loss,actuator drive abnormal or internal fault occurs,the controller will trigger relay alarm and display fault code on local panel.

Built‑in function

Turbine speed and load closed-loop control,extraction pressure regulation,overspeed protection,local HMI operation,used as Woodward 505E series turbine governor controller spare replacement.

Product Brief

5437-076 is Woodward old turbine series digital governor controller for single extraction steam turbine generator sets and power automation equipment.Confirm actuator and speed probe model matching before ordering.ESD protection required during handling and installation.
