XYCOM 4150 Industrial Operator Terminal Workstation

Technical Specifications

Model:4150

Brand:XYCOM

Product type:19 Inch Rack Mount PC/AT Industrial Operator Terminal Workstation

Power supply:100~240VAC,50/60Hz

Display:14 inch CRT color display

Input:Industrial membrane keypad

Processor:PC/AT compatible CPU

Memory:RAM onboard

Storage:Floppy disk drive,optional hard disk

Communication:RS232 / RS485 serial interface

Weight:29kg

Operating temperature:0℃ ~ +55℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:19 inch rack mount standard size

Certification:CE,UL,Class I Division2

System compatibility

4150 belongs to XYCOM 4100 series legacy rack mount operator workstation.

It can communicate with XYCOM VME bus SBC such as XYCOM 1840 and XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via serial port.

Commonly used for power plant,oil & gas,petrochemical old equipment monitoring,maintenance and spare replacement.

Function

Real-time display process parameters,trend curves,system alarms and equipment running status.

Membrane keypad for parameter setting,operation mode switching and manual control command input.

Bidirectional serial data exchange with VME main controller.

Local visual alarm indication when process abnormal occurs.

Power-on self-test for onboard hardware circuit detection.

Support MS-DOS operating system and XYCOM SoftScreen HMI configuration software.

Store alarm records and operation event logs.

Installation

Mount the unit into 19-inch cabinet rack and tighten fixing screws.

Connect 100~240VAC power cable and protective earth wire.

Wire serial communication cable to VME controller serial port.

Power on and run hardware self-test,configure serial baud rate and station address.

Load HMI project,verify keypad,CRT display and serial communication function.

Interface

AC power terminal,RS232/RS485 serial port,floppy drive,14 inch CRT display,membrane keypad,LED indicators:PWR,COMM,ALARM.

Feature

Standard 19-inch heavy-duty rack workstation design,built-in PC/AT compatible industrial computer.

14-inch CRT color display and heavy-duty membrane keypad,suitable for continuous industrial operation.

Dedicated serial interface to connect XYCOM VME control platform.

Run SoftScreen HMI software for old turbine control monitoring.

Discontinued legacy product,only used for old production system maintenance spare replacement.

Rugged metal chassis,anti-vibration and anti-electromagnetic interference for harsh plant environment.

Diagnostic

Check PWR and COMM LED;communication failure:check serial wiring,baud rate and station address;data abnormal:inspect floppy disk,system firmware and serial port hardware.

Product Brief

XYCOM 4150 is 4100 series heavy-duty rack mount industrial operator workstation.

It cooperates with XYCOM VME bus control system for field process monitoring and manual operation,widely used as spare parts for turbine and petrochemical old DCS control system renovation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
