XYCOM XVME-690 Processor Module

Technical Specifications

Model:XVME-690

Brand:XYCOM

Product type:VMEbus Single Board Computer Processor Module

Power supply:+5V VME backplane power

Bus interface:Standard VMEbus,bus master & slave,Tundra Universe II D PCI-VME bridge,support VME interrupt IRQ0~IRQ7

Form factor:6U single-height VME card

Weight:0.52kg

CPU:Intel Pentium M 1.8GHz (2MB L2 cache) or Celeron M 1.5GHz (1MB L2 cache),Intel SpeedStep technology

Memory:200-pin DDR ECC SODIMM socket,256MB/512MB/1GB/2GB optional,266/333MHz

Storage:EIDE Ultra DMA100 controller,2×SATA150 interface,floppy disk interface

Expansion:1×32/64bit PMC mezzanine card site,33/66MHz,dual PMC available via XVME-976 expansion card

Onboard communication:Dual 10/100/1000Mbps Gigabit Ethernet,2×RS232 serial port

Graphics:Integrated Intel 855GME graphics controller

Other onboard interfaces:USB,PS/2 keyboard,mouse,hardware watchdog timer

VME addressing:A16/A24/A32,D08/D16/D32

Onboard indicator:FAIL,PASS LED;RESET switch

Operating temperature:0℃ ~ +60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL

System compatibility

XVME-690 belongs to XYCOM XVME series high-performance VME single board computer.

It installs in XYCOM VME chassis and cooperates with XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via VME bus.

Commonly used for power plant,oil & gas,petrochemical old equipment maintenance and spare replacement.

Function

Act as main CPU controller of VME rack,run real-time operating system and complex process control programs.

Intel Pentium M / Celeron M processor executes control logic,high-speed data calculation and signal processing tasks.

ECC DDR memory ensures data integrity for high reliability critical control applications.

PCI-VME bridge realizes high-speed data exchange between local PCI peripherals and VME backplane.

PMC expansion slot supports flexible function expansion for communication and I/O modules.

Dual Gigabit Ethernet ports support redundant network communication for industrial field.

Integrated graphics,USB and serial ports for local display,debugging and peripheral connection.

Hardware watchdog timer monitors system running status,trigger automatic reset when program crash.

Full VME bus master function,access all VME I/O modules on backplane,collect field sensor data and output control instructions.

Support VME bus arbitration,system reset and VME interrupt management.

Onboard self-test for CPU,memory,graphics,storage,Ethernet,VME bus interface,fault state displayed via FAIL LED.

Installation

Power off VME chassis.

Insert XVME-690 card into empty 6U single-height VME slot,tighten front panel fixing screw.

Set base address,interrupt level via board jumpers.

Connect Ethernet,serial terminal,display or SATA/EIDE storage device wiring.

Power on chassis,run BIOS and hardware self-test.

The module acts as VME system master and initializes all rack I/O modules.

Interface

VME P1,P2 backplane connector,front panel RJ45,RS232,VGA,USB port,LED indicators and reset switch.

Feature

6U single slot VME single board computer,XYCOM XVME series.

Low power Pentium M / Celeron M industrial processor with SpeedStep dynamic power management.

ECC memory protection to avoid memory data error.

PMC expansion site,flexible function upgrade,dual PMC option with auxiliary expansion card.

Dual Gigabit Ethernet for redundant network.

SATA + EIDE dual storage interface,support solid-state storage.

Integrated Intel 855GME graphics,no extra video card required.

Full VME bus master capability,support 32-bit VME addressing and data transmission.

Discontinued obsolete VME module,supply only for old production system spare replacement.

Vibration resistant PCB design,suitable for turbine control cabinet.

Diagnostic

FAIL LED on:CPU fault,memory error,graphics/storage/Ethernet failure or VME bus interface damage;

Cannot boot:check backplane contact,SODIMM memory,BIOS setting and storage media;

Network/serial communication failure:check wiring,IP address,baud rate and transceiver circuit;

VME bus access error:check bus arbitration and interrupt jumper configuration.

Product Brief

XYCOM XVME-690 is legacy VMEbus 6U single board computer based on Intel Pentium M / Celeron M processor,with PMC and dual Gigabit Ethernet.

It serves as high-performance main controller for VME rack,widely used as spare part for turbine and compressor control,petrochemical and power plant old DCS renovation.

Disclaimer

All parameters are for reference only and not for quotation basis. Goods are scarce and will be powered on for inspection before shipment. Overseas delivery lead time 3-7 working days. This item is only used for equipment maintenance and retrofit.
