10140494 Pressure Switch Unit

Feature & Principle

Pressure acts on internal diaphragm or piston element. When pressure reaches set threshold, mechanical contact triggers to close or open circuit, sending switch signal to PLC or relay for pump startup, low-pressure alarm and equipment protection interlock.

Specifications

Model: 10140494 Signal: Dry contact switch output Media: Oil / compressed air Housing: Metal Protection: IP65 Mounting: Thread field mount Certification: CE

Components & Diagnostics

Sensing diaphragm, mechanical trip mechanism, micro switch, adjustment screw, threaded process connection. Common faults: set point drift, contact burn, diaphragm damage, no switching action.

Product Brief

10140494 pressure switch, machinery spare widely used for hydraulic station, lubrication system, air compressor and heavy equipment pressure protection.
