John Deere AL117365/36 Position Limit Switch Unit

Module Feature

AL117365/36 is John Deere original heavy-duty limit switch, widely matched on John Deere tractor, combine harvester and agricultural implement assemblies. It adopts mechanical roller or lever actuation structure, converts mechanical travel displacement into dry contact switching signal for position feedback and travel limit interlock. The housing is dustproof and splash resistant, suitable for field harsh working conditions with dust, vibration and humidity. Built-in silver alloy contact, stable switching performance, long mechanical service life. Terminal wiring design, easy to connect with vehicle ECU and control circuit.

Working principle

When moving mechanical part touches the switch actuator lever/roller, internal contact mechanism triggers and changes contact state (NO/NC). The ECU reads the signal state to judge whether the mechanism reaches preset position, and executes limit stop or safety interlock action. When the contact pressure disappears, the internal spring resets the switch automatically.

Onboard components

Cast plastic/metal housing, actuation lever and roller, internal spring assembly, NO/NC contact set, sealing gasket, multi-core wiring terminal.

LED indicators

No built-in indicator lamp.

Hardware self‑diagnosis

No electronic self-test; inspection relies on continuity test and manual stroke check.

Programming software

Not applicable, purely mechanical contact switch.

Electrical & Process Parameters

Model:AL117365/36 Brand:John Deere Device type:Mechanical Limit Switch Contact type:NO / NC dry contact Rated voltage:12V / 24V DC vehicle circuit Mounting:Bracket fixed installation Protection:IP64 Function:Mechanical travel position detection and safety limit interlock for agricultural machinery

Mechanical & Structure

Mounting:Bolt fixed on equipment bracket Protection class:IP64 Housing:Impact resistant engineering plastic

Environmental

Operating temperature:-30℃ ~ +85℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing Certification:Genuine John Deere OEM spare Status:Original John Deere spare switch

Installation

Fix switch bracket to the designated mounting position of the machine, adjust the gap between roller and trigger cam to guarantee reliable stroke action. Wire according to circuit diagram, distinguish normally open and normally closed contacts. After installation, manually trigger the switch and test signal feedback. Keep the actuator clean to avoid straw, mud and debris jamming.

InterfaceSignal wiring terminal block.

Diagnostic

No signal switching: Actuator stuck by dirt, contact burn or internal spring failure. Unstable signal: Loose mounting bracket, trigger cam misalignment or contact oxidation. Always closed / always open: Internal contact welding or fracture damage.

Product BriefJohn Deere AL117365/36 mechanical limit switch, OEM agricultural spare part, IP64, dry contact output, used for tractor and harvester travel position detection and safety limit interlock.
