2-W300N-HS12-01-FW Servo Drive Unit

Feature & Principle

It receives command signals from motion controller, converts DC power into regulated AC output to drive servo motor. Closed-loop feedback ensures accurate positioning, fast response and stable operation for continuous motion tasks.

Specifications

Model: 2-W300N-HS12-01-FW Control mode: Position / Speed / Torque Communication: High speed fieldbus Cooling: Air cooling Mounting: DIN rail or panel mount Certification: CE

Components & Diagnostics

Power module, control board, encoder interface, status LED, terminal block. Common faults: overcurrent alarm, encoder signal loss, communication interruption, overheating protection.

Product Brief

2-W300N-HS12-01-FW servo drive, motion control spare widely used for packaging, machine tool and handling automation equipment.
