32-1600 Pressure Sensor

Feature & Principle

It is a compact piezoresistive pressure transducer. The medium pressure acts on the isolation diaphragm and is transmitted to the sensing chip, converted into standard analog signal output for PLC or display instrument acquisition. It has shock and vibration resistance, suitable for hydraulic station, test bench and general industrial pipeline pressure measurement.

Specifications

Model: 32-1600 Power supply: 24VDC Output: 4-20mA 2-wire Wetted material: 316L stainless steel Process connection: NPT thread Protection grade: IP65 Application: Hydraulic system, test bench, machinery equipment pressure monitoring Certification: CE

Components & Diagnostics

Piezoresistive sensing chip, signal conditioning circuit, isolation diaphragm, wiring connector, status indicator. Common faults: signal drift, no output, diaphragm damage, short circuit.

Product Brief32-1600 pressure transducer, industrial hydraulic and machinery pressure monitoring spare widely used for equipment overhaul and replacement.
