ABB 3AXD50000007345 IGBT Power Module Kit Unit

Feature & Principle

This IGBT power module converts DC bus voltage into adjustable three-phase AC output to drive the motor. It works with the drive control board to realize variable frequency speed regulation. It is the core power component of the inverter, supporting heavy load and frequent start-stop working conditions.

Specifications

Model: 3AXD50000007345 Brand: ABB Type: IGBT power module kit Applicable drive: ACS800 series Voltage class: 1200V grade Mounting: Cabinet power plate installation Certification: CE, UL

Components & Diagnostics

IGBT power chip, heat sink, gate drive circuit, insulating accessories, fasteners. Common faults: IGBT breakdown, short circuit, overheating, gate drive abnormal, module insulation failure.

Product Brief

3AXD50000007345 IGBT power kit, ABB high-power inverter spare widely used for ACS800 drive overhaul and power unit replacement.
