ABB 3BSE023158R1 PFTL101BER‑2.0KN Tension Load Cell

Technical Specifications

Model:3BSE023158R1(PFTL101BER‑2.0KN)

Brand:ABB

Product Type:Pressductor vertical‑mount tension load cell

Rated Capacity:2.0KN

Working Principle:Pressductor magnetic stress measuring technology

Excitation:330Hz AC excitation

Signal Output:Proportional analog tension signal

Connector:Multi‑pin circular industrial connector

Mechanical Feature:Vertical installation structure,stainless steel housing

Feature:High anti‑interference,stable measurement,adapt for harsh workshop environment

System Compatibility:ABB Advant OCS,MasterPiece tension control system

Remark:Legacy EOL spare component;must verify rated force and installation mode before replacement

Module Form:Integrated mechanical‑electrical sensor unit

Weight:3.10 kg

Dimension:310 mm×110 mm×65 mm

Protection Grade:IP65

Certification:CE

Working Temperature:‑10℃ ~ +70℃,non‑condensing

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑95% non‑condensing

Application:Papermaking,film,textile industry,vertical‑type web tension detection for paper‑making machine,film slitting and textile finishing lines,real‑time tension signal collection for closed‑loop tension control,equipment overhaul and spare‑part replacement.

Product Details

3BSE023158R1,type PFTL101BER‑2.0KN,is vertical‑mount Pressductor series tension load cell of ABB.

Adopts Pressductor magnetic stress principle,converts mechanical web tension into proportional analog signal and transmits to upper tension processing board. Vertical installation design for specific mechanical mounting requirements. Stainless‑steel body adapts to humid and dusty workshop conditions. Circular multi‑pin connector for signal wiring. Sensor failure will cause tension reading drift,web jitter and web break risk. Widely used for paper‑making and film production line maintenance.

Note:This is legacy EOL spare component,widely used for process industry spare‑part replacement.
