ABB 57360001‑HC DSMC112 Floppy Disk Controller Module

Technical Specifications

Model:57360001‑HC(DSMC112)

Brand:ABB

Product Type:Floppy disk controller interface module

Matching Drive:3.5‑inch 1.44MB floppy disk drive

Bus Interface:MasterPiece local bus

Function:System program read‑write,configuration backup,data storage,off‑line project restore

Indicator:LED indicators for read‑write,ready,fault status

Feature:Rack plug‑in design,upgraded substitute for DSMC110(57330001‑N),improve transmission stability

System Compatibility:ABB Advant Master,MasterPiece200/1,Advant OCS DCS system

Remark:Legacy EOL spare component;confirm controller bus version before replacement,floppy drive sold separately

Module Form:Rack‑mount plug‑in PCB board

Weight:0.78 kg

Dimension:230 mm×100 mm×25 mm

Protection Grade:IP20

Certification:CE

Working Temperature:0℃ ~ +55℃,non‑condensing

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑95% non‑condensing

Application:Power plant,petrochemical,papermaking industry,used for old‑generation Advant series DCS controller program backup and project recovery,realize offline saving of control logic and parameter configuration,system overhaul and spare‑part replacement.

Product Details

57360001‑HC,type DSMC112,is floppy disk controller module for ABB Advant Master and MasterPiece200 DCS system,it is upgraded replacement of DSMC110.

It connects external 3.5‑inch floppy drive,complete controller program,configuration parameter and process data read‑write and offline backup,support project fault recovery. Rack plug‑in installation,equipped with multi‑group LED for status diagnosis. Module abnormal will cause floppy backup function failure,cannot complete offline program saving and restoring. Widely used for legacy Advant DCS site maintenance.

Note:This is legacy EOL spare component,widely used for process industry spare‑part replacement.
