ABB DSAB‑01C Diode Rectifier Board

Technical Specifications

Model: DSAB‑01C

Brand: ABB

Product Type: Diode rectifier power board

Diode Configuration: Bridge‑rectifier circuit structure

Repetitive Peak Reverse Voltage: 1600V

Average Forward Current: 100A per single diode

Built‑in Component: Power diodes, fuses, filter capacitors

Function: AC‑DC rectification, over‑current protection, power‑loop filtering

Interface: Multi‑pin plug‑in connectors for power and signal connection

Power Supply: Derived from drive main circuit

Operating Temperature: ‑20℃ ~ +70℃

Protection Class: IP20

Mounting: Rack‑slot installation inside drive cabinet

Compatible System: ABB old‑series drive and excitation power units

Core Function: Complete AC‑DC power rectification for power unit, provide over‑current fuse protection and circuit filtering

Product Details

The DSAB‑01C is a robust Diode Rectifier Board for ABB industrial drive and excitation power equipment, it is key Power‑unit Protection Board inside power conversion cabinet. It undertakes AC‑DC rectifying work, converts alternating current from main circuit into direct current for subsequent power unit operation.

Equipped with industrial high‑power diodes, fuses and filter capacitors, the board realizes bridge‑type rectification. The integrated fuse components offer fast over‑current protection to prevent damage caused by short‑circuit fault. Filter circuit suppresses power‑supply ripple and improves DC output quality. Multi‑pin plug‑in connectors simplify installation and replacement procedures.

Built‑in hardware monitoring detects fuse blown and internal component abnormal status. Fault signals can be transmitted to upper control board through signal terminals. Industrial‑grade circuit design adapts to high‑interference power cabinet environment.

Adopting standard rack‑slot installation inside drive cabinet. Widely applied in generator excitation, large‑variable‑speed drive and other industrial sites. It is essential power hardware for power unit overhaul, rectification circuit maintenance and defective diode board replacement.
