ABB DSDP140B 57160001‑ACX Digital Processing I/O Module

Technical Specifications

Model: DSDP140B

Part Number: 57160001‑ACX

Brand: ABB

Product Type: Digital processing I/O module

Channel Configuration: Multi‑channel discrete signal processing

Bus Interface: Advant internal backplane bus

Supply Voltage: 24 V DC

Operating Temperature: ‑40℃ ~ +70℃

Protection Class: IP20

Mounting: Rack‑mount slot installation

Compatible System: ABB Advant S400, Advant OCS DCS

Core Function: On‑site discrete signal pre‑processing and bus data forwarding

Product Details

The DSDP140B 57160001‑ACX is a signal processing I/O card belonging to ABB Advant S400 series, it acts as one DCS local processing component between field sensors and central controller. It undertakes pre‑processing of on‑site discrete signals, reducing the calculation burden of main controller by completing partial signal filtering and logic judgment locally.

This module connects field switches, proximity sensors and interlock contact signals through terminal base. It converts raw field level signals into standardized bus data, and transmits processed information to the main controller via Advant backplane bus. Local signal pre‑processing can filter out short‑time interference pulses caused by on‑site electromagnetic noise, effectively improving the stability of interlock logic in heavy‑industrial environment.

Built‑in channel diagnosis function can detect abnormal states such as open circuit and signal deviation, and upload fault information to DCS host through backplane. Maintenance engineers can view each channel’s operating status on HMI, shorten troubleshooting cycle for on‑site signal loop faults. Wide temperature design allows stable operation under severe temperature conditions of power plant and chemical workshops.

Designed for standard rack slot installation, it can be mixed and matched with other S400‑series I/O boards inside the same cabinet. It is widely used in thermal power, pulp‑paper and water‑treatment industries with large‑scale old DCS installations. It serves as practical hardware for system reconstruction, local signal expansion and aging board replacement of Advant OCS legacy control systems.
