ABB REA Arc Flash Protection System

Feature & Principle

ABB REA is a dedicated arc flash protection system, mainly including master unit REA101 and extension module REA105. It judges arc fault by combining arc optical signal and overcurrent signal. Once an arc fault is detected, it triggers rapid tripping to limit arc energy and protect switchgear and personnel. It supports fiber loop or radial sensor wiring, built-in self-supervision function to monitor fiber and circuit health status, and can realize breaker failure protection logic. It is widely used in medium and low voltage air insulated switchgear rooms.

Specifications

Model: REA series Brand: ABB Main unit: REA101 Extension module: REA105 Detection principle: Arc light + overcurrent dual criterion Sensor: Fiber optic arc sensor Output: High speed semiconductor trip output Communication: RJ45 interconnection between modules Application: MV / LV switchgear, power distribution cabinet arc flash protection Certification: CE, IEC 60255

Components & Diagnostics

Main protection unit, extension module, fiber optic arc sensor, power supply circuit, trip output circuit, status indicator. Common faults: fiber breakage, optical sensor pollution, communication disconnection, trip output failure, power supply abnormality.

Product Brief

REA arc protection system, ABB fast arc flash safety protection spare widely used for power distribution switchgear overhaul and replacement.
