ABB UFC721AE 3BHB002916R0001 Analog Signal Conditioning Scaling Card

Technical Specifications

Model: UFC721AE

Part Number: 3BHB002916R0001

Brand: ABB Bailey

Product Type: Analog signal conditioning scaling termination card

Matching System: ABB Bailey INFI90, Symphony Plus DCS system

Power Supply: Backplane DC power supply

Signal Mode: Field analog signal conditioning, range conversion via DIP switch setting

Isolation Mode: Channel‑to‑bus galvanic isolation

Installation Method: I/O rack plug‑in card installation

Operating Temperature: 0℃ ~ +60℃, non‑condensing

Protection Class: IP20

Weight: 0.38kg

Dimension: 220mm × 145mm × 28mm

Compatible System: Power plant, petrochemical industry distributed control system

Core Function: Receive field analog signals, complete signal filtering, isolation and range scaling conversion, transmit processed standard signals to DCS controller, realize accurate collection of process measurement signals.

Product Details

The UFC721AE 3BHB002916R0001 is analog signal conditioning scaling card for ABB Bailey INFI90 and Symphony Plus DCS system.

This UFC721AE card works as analog front‑end signal processing unit for Harmony I/O rack. It converts various non‑standard field sensor signals into standardized signals applicable for DCS controller acquisition.

Signal range can be flexibly configured by on‑board DIP switches to adapt to different field transmitter and sensor types.

Each channel adopts galvanic isolation design, effectively suppresses common‑mode interference from industrial site and improves measuring accuracy and stability.

It filters noise interference mixed in field signals, ensures reliable and stable data transmission to main control processor.

Built‑in hardware self‑diagnosis function can detect signal over‑range and channel abnormality, and output corresponding alarm information.

Standard plug‑in structure supports convenient on‑site overhaul and replacement without modifying controller configuration.

Widely applied in thermal power, petrochemical and other large‑scale process industry DCS transformation and maintenance projects.

It is important spare hardware for DCS system overhaul, analog signal loop debugging and defective UFC721AE card replacement.
