Atlas Copco PF063-2102-S9-115R Tightening Controller

Technical Specifications

Model:PF063-2102-S9-115R Brand:Atlas Copco Product Type:Tensor S9 Tightening Controller Power Supply:115V AC,50/60Hz,200W Mounting:Cabinet rack mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:9.2kg Dimension:405mm305mm160mm

System compatibility

PF063-2102-S9-115R belongs to Atlas Copco Tensor S9 series single-tool tightening controller. Compatible with Tensor S9 series electric nutrunner tools. It is 115R version designed for 115Nm torque range, equipped with communication expansion slot. This torque controller can communicate with PLC and MES system for fastening result upload, production traceability and remote parameter control, ideal for single tool assembly control applications as an industrial spare part.

Function

PF063-2102-S9-115R is compact torque controller unit for automated bolt assembly. This Atlas Copco Tensor S9 tightening controller supports multi-step tightening sequences, real-time torque-angle curve monitoring and OK/NOK fastening judgement. It stores fastening history records and supports parameter backup, built-in emergency stop safety relay, widely used for single tool assembly control at automotive component and general machinery assembly stations, serving as reliable industrial spare part.

Installation

Cut off power before installation. Mount the PF063-2102-S9-115R Atlas Copco tightening controller inside electrical cabinet. Connect AC power, tool motor cable and signal wiring. Install optional fieldbus module if required. Configure tightening programs via ToolsTalk software. Complete tool calibration and test tightening before online operation of this Tensor S9 torque controller.

Interface

Single tool drive port, 24V digital I/O terminals, communication expansion slot, basic front operation panel, status LED indicators, E-stop safety relay terminal for PF063-2102-S9-115R Atlas Copco tightening controller.

FeatureAtlas

 Copco Tensor S9 torque controller, 115V power input, 115Nm torque rating, modular communication expansion design, real-time torque-angle monitoring, built-in E-stop safety relay, fastening data storage, IP20 cabinet protection. This discontinued legacy industrial spare part is used for single station bolt tightening system maintenance and replacement.

Diagnostic

Controller no power: check AC input, fuse and wiring for PF063-2102-S9-115R. Tool no rotation: inspect tool cable, motor winding and tool enable signal. Tightening result deviation: verify tool calibration, tightening program and joint mechanical condition of this tightening controller. Communication abnormal: check communication module, bus cable, node address and PLC configuration of the Atlas Copco torque controller. Front panel display fault: check internal display connector and controller firmware.

Product

BriefPF063-2102-S9-115R is Atlas Copco Tensor S9 tightening controller. This torque controller widely used in automotive and machinery assembly production lines for single tool assembly control, supports optional communication module for factory network communication, popular industrial spare part for bolt fastening control.
