Atlas Copco PF4002-C-EIP-HW Tightening Controller

Technical SpecificationsModel:PF4002-C-EIP-HW Brand:Atlas Copco Product Type:Power Focus4002 Basic Tightening Controller with Ethernet/IP Power Supply:100-120 / 200-240V AC,50/60Hz,150W Mounting:Cabinet rack mount Operating temperature:5℃ ~ +40℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:11.6kg Dimension:415mm319mm173mm

System compatibilityPF4002-C-EIP-HW belongs to Atlas Copco Power Focus4002 series single-tool tightening controller. Compatible with Tensor ST / SL / DS series electric nutrunner tools. It is C basic version without Graph HMI, built-in Ethernet/IP fieldbus interface. This torque controller can communicate with PLC and MES system for fastening result upload, production traceability and remote parameter control, ideal for single tool assembly control applications as an industrial spare part.

FunctionPF4002-C-EIP-HW is compact torque controller unit for automated bolt assembly. This Atlas Copco Power Focus4002 tightening controller supports multi-step tightening sequences, real-time torque-angle curve monitoring and OK/NOK fastening judgement. It stores fastening history records and supports parameter backup, built-in emergency stop safety relay, widely used for single tool assembly control at automotive component and heavy machinery assembly stations, serving as reliable industrial spare part.

InstallationCut off power before installation. Mount the PF4002-C-EIP-HW Atlas Copco tightening controller inside electrical cabinet. Connect AC power, tool motor cable and Ethernet/IP communication cable. Configure tightening programs via ToolsTalk software. Complete tool calibration and test tightening before online operation of this Power Focus4002 torque controller.

InterfaceSingle tool drive port, 24V digital I/O terminals, Ethernet/IP port, basic front operation panel, status LED indicators, E-stop safety relay terminal for PF4002-C-EIP-HW Atlas Copco tightening controller.

FeatureAtlas Copco Power Focus4002 torque controller, C basic version, built-in Ethernet/IP communication interface, real-time torque-angle monitoring, built-in E-stop safety relay, fastening data storage, IP20 cabinet protection. This discontinued legacy industrial spare part is used for single station bolt tightening system maintenance and replacement.

DiagnosticController no power: check AC input, fuse and wiring for PF4002-C-EIP-HW. Tool no rotation: inspect tool cable, motor winding and tool enable signal. Tightening result deviation: verify tool calibration, tightening program and joint mechanical condition of this tightening controller. Ethernet/IP communication abnormal: check network cable, IP address, PLC configuration and switch status of the Atlas Copco torque controller. Front panel display fault: check internal display connector and controller firmware.

Product BriefPF4002-C-EIP-HW is Atlas Copco Power Focus4002 series tightening controller. This torque controller widely used in automotive and machinery assembly production lines for single tool assembly control, built-in Ethernet/IP interface for factory network communication, popular industrial spare part for bolt fastening control.
