Atlas Copco TC54P-N Tightening Controller

Technical SpecificationsModel:TC54P-N Brand:Atlas Copco Product Type:TC5000 Series High Power Servo Tightening Controller with Profinet IO Power Supply:200-480V AC,50/60Hz,500W Mounting:Cabinet DIN rail mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:6.1kg Dimension:220mm130mm300mm Protection:IP20

System compatibilityTC54P-N belongs to Atlas Copco TC5000 series single spindle high-power servo tightening controller. Compatible with high-torque Atlas Copco servo nutrunner spindles for heavy-duty fixed assembly stations. It is equipped with built-in Profinet IO fieldbus interface, supporting connection to Siemens and other mainstream Profinet PLC systems. This controller uploads tightening results and full traceability data to PLC and MES system, suitable for heavy load high-precision single spindle bolt tightening on automotive and heavy machinery assembly lines as industrial spare part.

FunctionTC54P-N is high power precision servo torque controller for heavy-duty single spindle assembly station. This Atlas Copco TC5000 controller supports multi-step tightening sequences, real-time torque-angle curve monitoring and OK/NOK tightening judgement. It stores massive tightening history records and supports parameter backup, built-in emergency stop safety relay, widely used for heavy bolt assembly at automotive and heavy machinery assembly stations, serving as reliable industrial spare part.

InstallationCut off power before installation. Mount the TC54P-N Atlas Copco controller on DIN rail inside electrical cabinet. Connect AC power, high-torque servo spindle motor cable and Profinet IO communication cable. Configure tightening programs via ToolsTalk software. Complete spindle calibration and test tightening before online operation of this TC5000 controller.

InterfaceHigh power servo spindle drive port, digital I/O terminals, Profinet IO port, Ethernet service port, front operation panel, status LED indicators, E-stop safety relay terminal for TC54P-N Atlas Copco tightening controller.

FeatureAtlas Copco TC5000 high power single spindle servo controller, built-in Profinet IO fieldbus, service Ethernet port, real-time torque-angle monitoring, built-in E-stop safety relay, large capacity tightening data storage, IP20 cabinet protection. This discontinued legacy industrial spare part is used for heavy load single spindle bolt tightening system maintenance and replacement.

DiagnosticController no power: check AC input, fuse and wiring for TC54P-N. Spindle no rotation: check spindle cable, motor winding and enable signal. Tightening result deviation: verify spindle calibration, tightening program and mechanical condition of this controller. Profinet IO communication abnormal: check network cable, device name, PLC configuration and switch status of the Atlas Copco controller. Front panel display fault: check internal display connector and controller firmware.

Product BriefTC54P-N is Atlas Copco TC5000 series high-power single spindle servo tightening controller. This controller widely used in automotive and heavy machinery assembly production lines for heavy load high precision single spindle tightening, built-in Profinet IO interface for factory network communication, popular industrial spare part for fixture assembly system.

Disclaimer:All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
