BAUMULLER 344284 Servo Motor Feedback Unit

Technical Specifications

Model: 344284 Brand: BAUMULLER (Baumüller, Germany) Product Type: Servo Motor Feedback Assembly Mounting: Installed at the rear end of BAUMULLER servo motor Operating temperature: 0℃ ~ +60℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP54 (when fully assembled on motor)

System compatibility

344284 matches BAUMULLER servo motors and b maXX series servo drives. It fits printing, metal forming and plastic machinery servo systems for overhaul and fault replacement.

Function

344284 is the feedback assembly mounted on servo motor. It captures rotor position and speed signals, transmits real-time feedback data to servo drive for closed-loop motion control. It ensures precise speed and positioning control of servo motor. It is used to replace aged or damaged feedback assemblies during motor maintenance.

Installation

Cut off all power of servo system before installation. Disassemble the motor rear housing, remove old feedback assembly. Install 344284, align the rotor coupling and secure mounting fasteners. Reconnect feedback cable to drive, perform position offset calibration, test motor operation before formal use.

Interface

Signal cable connector, mechanical coupling interface for 344284 BAUMULLER feedback assembly.

Feature

Original Baumüller feedback assembly, high resolution position detection, shock resistance, compact rear-mount design, industrial anti-interference design. This legacy spare part is used for on-site maintenance of old BAUMULLER servo motor systems.

Diagnostic

Drive reports position feedback error: check coupling alignment and cable connection for 344284. Motor positioning drift: inspect signal integrity and assembly installation gap. Intermittent speed fluctuation: check connector shielding and component aging.

Product Brief

344284 is German BAUMULLER servo motor feedback assembly. It collects rotor position and speed signals for closed-loop control, classic spare part for legacy BAUMULLER servo motor overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
