ABB 5SGY3545L0008 IGCT Power Module

Technical Specifications

Model:5SGY3545L0008

Brand:ABB

Product Type:IGCT integrated gate commutated thyristor(press‑pack hockey‑puck structure,without integrated gate drive board)

Voltage class:4500V

Repetitive peak off‑state voltage VDRM:4500V

Typical turn‑off current:3500A

Gate control:Matching external independent gate drive unit

Cooling mode:Press‑pack clamping installation,air‑cooled or liquid‑cooled heat sink

Max junction operating temperature:125℃

Installation:Strictly follow specified clamping force,clamped between two heat sinks

Feature:Snubberless turn‑off capability,low on‑state loss,hockey‑puck press‑pack package

System Compatibility:ABB ACS6000 medium‑voltage converter,ARU active rectifier,three‑level inverter,STATCOM static var compensator

Remark:Legacy EOL spare component;external gate drive unit required,clamping force must comply with official specification

Module Form:Disc‑type press‑pack power semiconductor device

Weight:2.72 kg

Dimension:132mm×132mm×76mm

Protection Grade:IP00

Certification:CE

Operating Temperature:‑40℃ ~ +125℃(junction),‑20℃ ~ +70℃(ambient)

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑95% non‑condensing

Application:Metallurgy,mining,new‑energy power quality industry,core power switching device for ACS6000 medium‑voltage drive ARU and inverter unit,also applicable to static var compensator STATCOM and large‑capacity power conversion equipment,equipment overhaul and spare‑part replacement.

Product Details

5SGY3545L0008 is ABB hockey‑puck press‑pack IGCT power semiconductor device,mainly applied to ACS6000 medium‑voltage frequency converter.

Adopt integrated gate commutation thyristor technology,support snubberless turn‑off;need to cooperate with external independent gate drive unit to complete trigger and fault feedback;hockey‑puck disc press‑pack structure,must install according to specified clamping force,match heat sink for heat dissipation. Device damage will cause power unit failure and converter shutdown. Widely used for legacy medium‑voltage drive and power‑quality equipment site maintenance.

Note:This is legacy EOL spare component,widely used for high‑power power‑electronic spare‑part replacement.
