DANAHER MOTION DSM100 Servo Drive

Technical Specifications

Model：DSM100 Brand：DANAHER MOTION (Kollmorgen / Giddings & Lewis) Product Type: Centurion series digital servo amplifier for industrial CNC motion control

Drive Feature: Control mode: Position / Speed / Torque control Command interface: SERCOS digital bus, auxiliary master encoder input Built-in function: Electronic gearing, homing routine, S-curve acceleration, removable personality parameter module, shunt resistor PWM switching frequency: High resolution multi-processor digital control

Electrical Parameters: Input voltage:100~240VAC single / three phase Power range:1.0kW ~15kW according to sub-models Built-in 24VDC I/O power supply

Mechanical & Structure: Housing: Metal sheet enclosure Mounting: Cabinet panel mounting Cooling: Forced air cooling Protection class: IP20

Environmental: Operating temperature:0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved

System compatibility

DSM100 belongs to DANAHER MOTION Centurion DSM servo drive family. Compatible with NSM, YSM, FSM, HSM series Giddings & Lewis / Kollmorgen brushless servo motors. Widely used for heavy-duty CNC machine tools and high-performance automation production lines.

Function

DSM100 Centurion is high-performance digital servo amplifier manufactured by DANAHER MOTION. It receives motion commands via SERCOS fieldbus, outputs adjustable drive power for brushless or induction motors. Full digital closed-loop control delivers high-precision positioning and fast dynamic response. Removable personality module saves all drive parameters, simplifies replacement and commissioning.

Installation

Follow lockout/tagout safety procedure before installation. Mount DSM100 firmly inside electrical cabinet. Connect AC power cable, motor power cable and encoder feedback cable strictly follow Giddings & Lewis DSM100 installation manual. Complete motor auto-tuning and full-load motion test during commissioning.

Interface

AC power terminals, motor output terminals, encoder feedback port, SERCOS communication port, digital I/O terminals, status LED indicator for DANAHER MOTION DSM100.

Feature

Original DANAHER MOTION DSM100 Centurion servo drive,SERCOS digital bus,removable parameter module,built-in 24V I/O supply,short circuit protection,UL & CE certified. This spare unit is used for heavy-duty CNC axis control,motion system maintenance and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage,undervoltage,overcurrent and overtemperature faults. Motor no rotation: Check power wiring,encoder connection,SERCOS communication and drive enable signal. Positioning deviation: Re-tune servo gain,inspect feedback signal and mechanical backlash. Abnormal vibration: Adjust servo parameters,check motor and coupling alignment.

Product Brief

DSM100 is DANAHER MOTION Centurion series high-performance SERCOS digital servo amplifier,supports multi-mode control,matched with Giddings & Lewis NSM/YSM/FSM/HSM servo motors,classic spare part for heavy-duty CNC industrial automation machinery.
